Hardware specifications TX 4000 PCI SS7 Network Interface Board Installation Manual
H.100 compliant interface
H.100 compliant interface has the following features:
• Flexible connectivity between T1 and E1 trunks and the H.100 bus
• Access to any of 4096 H.100 timeslots
• Compatible with any H.100 compliant telephony interface
• H.100 clock master or clock slave
• H.100 bus termination capability
Environment
Feature Description
Operating temperature 0 to 50 °C
Storage temperature -20 to 70 °C
Humidity 5% to 80%, non-condensing
Software environment
Feature Description
Development environment NaturalAccess Software
Operating system Windows
UNIX
Power requirements
State Requirements
TX 4000 0.1 A maximum @ 12.0 V
0.5 A maximum @ 5.0 V
6.5 A maximum @ 3.3 V
Connectivity
Feature Description
Ethernet
connectivity Two 10/100Base-T Ethernet interface with RJ-45 connectors for connecting to either
a network of other SIGTRAN devices or for connecting to a redundant mate board.
PSTN network
connectivity Two T1/E1 Dialogic ® MD1 RJ-45 interfaces
Intra-chassis
connectivity H.100 bus. Lucent Ambassador T8100A with 256 half duplex or 128 full duplex
timeslots
