Configuring the TX 4000 board TX 4000 PCI SS7 Network Interface Board Installation Manual
Removing a board
Complete the following steps to remove a TX board from the system:
Step Action
1 Power down the system if it is running.
2 Remove the TX 4000 board from the slot.
3 Power up the system.
4 Verify the configuration change by entering the following command:
txcpcfg
For example, if you remove a TX board with a CP number of 2, no configuration information for
the removed board is displayed, as in the following example:
Bus Slot CP Number CP Model
2 2 1 TX 4000
2 8 3 TX 4000
5 Save the configuration changes.
In a Windows system, configuration changes are saved automatically. In a UNIX system,
configuration changes are deleted when you restart the system. Save the changes by editing the
cpcfg file as described in Saving configuration changes on page 27.
