Hardware specifications
General hardware specifications
This topic describes the following types of hardware specifications:
• Physical
• Host interface
• H.100 compliant interface
• Environment
• Software environment
• Power requirements
• Connectivity
Physical
Feature Specification
Form factor Standard length PCI board
PCI bus 33/66 MHz, 32-bit master/target or slave 5.0 V or 3.3 V signaling compatible slot
Input/output PCI end bracket
Board weight 0.40 lb (0.20 kg)
Host interface
Feature Specification
Electrical PCI bus designed to PCI Local Bus Specification Revision 2.2
Mechanical Designed to PCI Local Bus Specification Revision 2.2
Bus speed DC to 66 MHz
Maximum number of boards per chassis 16
Maximum number of SS7 links per board 32 per TX 4000 board
16 per TX 4000/20 board
I/O mapped memory Memory mapped interface for efficient block data transfers
Plug and play Compatible (Windows only)
