6 Introduction
Table 1-4: Digital Trigger Output
1.3.4 General Specifications
Digital Trigger Output
Compatibility
5 V TTL
Output high threshold (VOH) 2.4 V
Output low threshold (VOL) 0.2 V
Trigger polarity Positive or negative
Pulse width
50 ns, 100 ns, 150 ns, 200 ns, 500
ns, 1 μs, 2 μs, 7.5 μs, and 10 μs
Trigger output driving capacity Capable of driving 50Ω load
Specifications
Physical dimensions 160 (W) x 100 (H) mm (6.24 x 3.9 in.)
Bus
Bus interface PCI Express Gen 2 x 4
Environmental Tolerance
Operating
Temperature: 0°C - 55°C
Relative humidity: 5% - 95%, non-condensing
Storage
Temperature: -20°C - +80°C
Relative humidity: 5% - 95%, non-condensing
Calibration
Onboard reference
+5 V and +2.5 V
Temperature coefficient 3.0 ppm/°C
Warm-up time 15 minutes
Power Consumption
Power Rail Standby Current (mA) Full Load (mA)
+3.3 V 766 782
12 V 882 970
