Page 49: Data structure variables
Monitoring/Control Functions
39
PXIs-2719A
BYTE FanFullSpeed; //Fan in Full or Auto
Speed Mode
} ChassisSetting;
4.1.3
MCUVersion
Includes MCU Code Version, Major Number, and Minor Number
typedef struct tagMCUVersion
{
BYTE MajorNo;
BYTE MinorNo;
} MCUVersion;
4.1.4
Data Structure Variables
Variables in the Data Structure are as follows
Variable
Description
Type
Value
PowerStatus
Power On/Off status
BYTE
0: Off
1: On
Fan1Status
Fan#1 operating status
BYTE
0: Normal
1: Abnormal
2: Disabled
3: Stopped
Fan2Status
Fan#2 operating status
BYTE
Fan3Status
Fan#3 operating status
BYTE
Fan1RPM
Fan#1 speed in RPM
int
RPM value
Fan2RPM
Fan#2 speed in RPM
int
Fan3RPM
Fan#3 speed in RPM
int
Temp1Status
Temperature sensor #1 status
BYTE
0: Normal
1: Abnormal
Temp2Status
Temperature sensor #2 status
BYTE
Temp3Status
Temperature sensor #3 status
BYTE
Temp4Status
Temperature sensor #4 status
BYTE
Temp5Status
Temperature sensor #5 status
BYTE
Temp6Status
Temperature sensor #6 status
BYTE
Temp7Status
Temperature sensor #7 status
BYTE
Temp8Status
Temperature sensor #8 status
BYTE
