A2.1 Introductions
DIN-96DO digital output termination board features high-voltage opto-
isolation on all outputs to prevent floating potential and ground loop
problems from damaging your PC system. It is composed of one TB-96
base board, one TB-96DO daughter board, and one DIN socket for easy
maintenance, wiring, and installation. It provides 96 channels that are
accessed through a SCSI-100 connector.
A2.2 Features
u
96 Opto-Isolated digital output channels
u
For use with the PCI-7396
u
On-board relay driver circuitry
u
Screw terminals for easy field wiring
A2.3 Specifications
u
Numbers of channel: 96
u
Opto-isolator: PC3H7
u
Output type: Darlingtoin transistors, open collector up to 35Vdc
u
Sink current:
w
350mA max.@ 100% duty, one of transistors device ON
w
370mA @ duty 10% for all transistors devices ON
w
140mA @ duty 50% for all transistors devices ON
w
60mA @ duty 100% for all transistors devices ON
u
Isolation voltage: 2500 Vrms
u
Dimensions: 112.7 mm x 225.0 mm
u
Operating temp.: 0
°
~ 60
°
C
u
Storage temp.: -20
°
~ 80
°
C
u
Humidity: 5~95%, non-condensing
u
Power consumption:
