20
• Registers Format
3.6 External Trigger Disable Register
Users can write anything to this register to disable the function of external
trigger.
Address: BASE + 0Ch
Attribute: write only
Data Format:
Bit 7 6 5 4 3 2 1 0
BASE+0C
h x x x x x x x x
BASE+0D
h x x x x x x x x
BASE+0E
h x x x x x x x x
BASE+0Fh x x x x x x x x
3.7 Change of State (COS) Control Register
This register is used to configure the COS interrupt.
Address: BASE + 60h
Attribute: write only
Data Format:
Bit 7 6 5 4 3 2 1 0
BASE+60h x x x x x P1C P1B P1A
BASE+61h x x x x x x x x
BASE+62h x x x x x x x x
BASE+64h x x x x x x x x
P1n : n: port number
Set to be ‘0’ to disable COS , ‘1’ to enable COS
