Registers
• 27
Write 1 to clear the trigger status:
0: no effect
1: clear trigger detect status
Clear SC_TC(Bit2) : Write 1 to clear
Write 1 to clear Scan Counter Terminal Count status
0: no effect
1: clear the SC_TC status
Clear ADOR(Bit1) : Write 1 to clear
Write 1 to clear the A/D Overrun Status
0: no effect
1: clear the A/D Overrun status
Clear ADOS(Bit0) : Write 1 to clear
Write 1 to clear the A/D Over Speed Status:
0: no effect
1: clear the A/D Over-Speed status
4.8 A/D & FIFO Status Register
Address: BASE + 28
Attribute: read
Data Format:
Bit 7 6 5 4 3 2 1 0
ACQ Full HFull Empty Trg_det SC_TC ADOR ADOS
Bit 15 14 13 12 11 10 9 8
--- --- --- --- --- --- --- ---
Bit 23 22 21 20 19 18 17 16
--- --- --- --- --- --- --- ---
Bit 31 30 29 28 27 26 25 24
--- --- --- --- --- --- --- ---
Table 11. A/D & FIFO Status Register
