• Introduction
1.1 Features
The 9116 series CompactPCI Advanced Data Acquisition Card provides the
following advanced features:
•
32-bit PCI-Bus, plug and play
•
Up to 64 single-ended inputs or 32 differential inputs, mixing
of using SE and DI analog signal sources
•
16-bit analog input resolution
•
On-board A/D 1K FIFO memory
•
512 words analog input Channel Gain Queue spaces
•
Sampling rate up to 250KS/s
•
Bipolar or Unipolar input signals
•
Programmable gain of x1, x2, x4, x8
•
Jumper-less and software configurable
•
Five A/D trigger modes: software trigger, pre-trigger,
post-trigger, middle-trigger and delay-trigger
•
Software Polling, Interrupt and Bus-mastering DMA data
transfer available
•
8 digital input and 8 digital output channels
•
100-pin D-type SCSI-II connector for cPCI-9116
•
100-pin D-type SCSI-II connector on a rear I/O transition
board for cPCI-9116R
•
Compact size: standard compact PCI 3U size
1.2 Applications
•
Automotive Testing
•
Cable Testing
•
Transient signal measurement
•
ATE
•
Laboratory Automation
•
Biotech measurement
