Signal Connections
• 13
3
Signal Connections
This chapter describes the connectors of the 9116 series. The signal
connections between the 9116 series cards and external devices are also
outlined.
3.1 Connectors and Pin Assignment
The cPCI-9116 is equipped with one 100-pin SCSI-type connector (J1).
J1 is used for digital input/output, analog input, and timer/counter signals. The
pin assignment for the connector is illustrated in the Figure 3.1.
With the REAR I/O adaptor specifically designed for the cPCI-9116R, the
cPCI-9116R connector pin assignments are identical to that of the cPCI-9116.
The red LED positioned on the front panel is used as a power indicator.
