INSTALLATION

2

2.8.3

Replacing Gryphon™ M Batteries


To change the batteries in your Gryphon™ Mx30 scanner, proceed as follows:

1.

Unscrew the battery cover screw.

Battery

Cover Screw

2.

Open the battery cover.

3.

Replace the
ones, then
back in pla

old batteries with new

screw the battery cover

ce.

to

NiMh, or Alkaline AA Batteries


WARNING

Do not incinerate, disassemble, short terminals or expose to
high temperature. Risk of fire, explosion. Use specified
charger only. Risk of explosion if the battery is replaced by
an incorrect type. Dispose of the batteries as required by the
relevant laws in force.


+

-

Battery
Cover

9
