GRYPHON™ Dx30/Mx30
6
6.4 SYSTEM AND RADIO FEATURES
Radio Features
Working Frequency 433.92 MHz
Bit Rate 19200
Range (in open air) 30 m
RF Modulation FSK
System Configurations OM-GRYPHON™ STARGATE™
Maximum number of devices per
base stations
16 255
Maximum number of devices in the
same reading area
2000
Maximum number of base stations
in network
- 16
6.5 STATUS INDICATORS
The reader has three indicators, LED, Beeper and Good Read Spot. The
OM-Gryphon™ and C-Gryphon™ cradles have three indicator LEDs. They signal
several operating conditions which are described in the tables below.
H = high tone L = low tone
GRYPHON™ Dx30/Mx30 READER START-UP
Beeper ¹ Meaning
L L L L Parameters loaded correctly
H H H H
long tones
Parameter loading error, reading or writing error in the non volatile
memory
H L H L Hardware error in EEPROM
GRYPHON™ Dx30/Mx30 READER CONFIGURATION
Beeper ¹ Meaning
H H H H Correct entry or exit from Configuration mode
L Good read of a command
L L L Command read error
