DESIGNATOR ALTEC PART
NUMBER
DESCRIPTION
VR501, 502 47-06-0373961 4> 16 K161 MOO-
100KB CC
VR503 47-06-0376861
VR601 47-06-0373971 12 K121 LOO-IOKA
VR602 47-06-0373981 4> 12 K121 LOO-
lOKRD
VR603 47-06-0376871 12 K121 LOO-
lOOKB CC
TONE LEVEL
ADJUST
47-06-0376881 4> 16 lOKAxl
R127-130 47-01-124825 WW CE 0.27il 5W R
ROOD, 006 47-01-0372011 MO ion IW 5%
R131 47-02-0374241 MO ion 3W W/COIL
R132 47-01-0372481 MO 4.7n 2W 5%
ROlO-012 47-01-0374171 WW CE 220n 5W R
R133 47-01-0376901 MO 270n IW 5%
R015 47-01-0374131 MO 560n 2W 5%
R026, 213 47-01-0374261 MO 680n IW 5%
R028 47-01-0374141 MO IKn 2W 5%
R027 47-01-124803 MO 1.2Kn IW 5%
R601, 602 47-01-0376911 CF 33n 1/5W 5%
R623 47-01-0376921 CF 47n 1/5W 5%
R114 47-01-0374221 CF
68n
1/5W 5%
R331 47-01-0371201 CF lOOn 1/5W 5%
R617, 619 47-01-0376941 CF 200n 1/5W 1%
RI15, 116, 906 47-01-0372521 CF 220n 1/5W 5%
R118, 120
(1715C)
47-01-0372101 CF 470n 1/5W 5%
(1715C)
R616 47-01-0376951 CF l.OOkn 1/5W 1%
R118, 120
(1707C)
47-01-0371221 CF 1.5 kn 1/5W 5%
(1707C)
R107 47-01-0374231 CF 560n 1/5W 5%
R105, 106,
123-126, 404
47-01-0371211 CF Ikn 1/5W 5%
R606, 633 47-01-0373711 CF 1.2kn 1/5W 5%
DESIGNATOR ALTEC PART
NUMBER
DESCRIPTION
RlOl 47-01-0371221 CF 1.5kn 1/5W 5%
R029, 030,
413, 416, 505,
506, 607 47-01-0376961 CF 2.2kn 1/5W 5%
R909 47-01-0372531 CF 3kn 1/5W 5%
R618 47-03-0376971 CF 3.24kn 1/5W 1%
R415, 910, 911 47-01-0372541 CF 3.3kn 1/5W 5%
R008, 009,
402, 905 47-01-0371661 CF 4.7kn 1/5W 5%
R417, 305 47-01-0372551 CF 5.6kn 1/5W 5%
R627, 628,308
Note: If Q302
is a
KTC1815(Y), 47-01-0371681 CF 7.5kn 1/5W 5%
then R308 is: 47-01-0371251 CF 15kn 1/5W 5%
R319, 504 47-01-0372561 CF 8.2kn 1/5W 5%
R002, 003,
119, 110-113,
208, 608-611,
630, 631, 904
47-01-0371691 CF lOkn 1/5W 5%
R502, 702,
706, 912 47-01-0371241 CF 12kn 1/5W 5%
R017, 103,
104, 108, 212
47-01-0371251 CF 15kn 1/5W 5%
R621 47-03-0377001 CF15.0kn 1/5W 1%
R018 47-01-0371711 CF 18kn 1/5W 5%
R117 47-01-0371721 CF 20kn 1/5W 5%
R121, 122
(1715C)
47-01-0374211 CF 20 kn 1/5W 5%
(1715C)
R620, 626 47-03-0377011 CF 30.Ikn 1/5W 1%
R121, 122
(1707C)
47-01-0372581 CF 47kn 1/5W 5%
(1707C)
ROOl, 022,
102, 403, 414
47-01-0372571 CF 22kn 1/5W 5%
R330 47-01-0373571 CF 27kn 1/5W 5%
R020, 204,
320, 47-01-0371741 CF 33kn 1/5W 5%
R615 47-03-0377031 CF 39.2kn 1/5W 1%
R908 47-01-0372851 CF 47kn 1/5W 5%
