Altec Lansing 1715C - Manual (Page 21)

DESIGNATOR ALTEC PART
NUMBER
DESCRIPTION
IC 001 17-01-124804 TA 7317 P
IC 201 17-01-0374081 GD 74HC 368
IC 301, 501 17-01-027463 NJM 4558 DD
IC 605 17-01-0374061 SSM 2120
IC 602 17-01-0374111 TD 62507 P
IC 601 17-01-122833 NJM 5532 DD
IC 701 17-01-0374121 NJM 2068 DD
1C 603, 604 17-01-0374071 KIA 7359 P
Q114, 115
(1715C)
48-03-124821 NPN 2SC 3281
(1715C)
Q114, 115
(1707C)
48-03-0377261 NPN 2SD 718 (1707C)
Q116, Q117
(1715C)
48-03-124820 PNP 2SA 1302
(1715C)
Q1I6, 117
(1707C)
48-03-0377271 PNP 2SB 688 (1707C)
QlOl-104, 107,
901 48-03-124824 NPN KTC 2240 BL
Q105, 106 48-03-0372371 PNP 2SA 965 Y
Q108, Q109 48-03-0374361 NPN 2SC 2235 Y
QUO 48-03-124822 NPN 2SC 2238 Y
Qlll 48-03-0372361 PNP 2SA 968 Y
QOOl, 408 48-03-0372721 NPN KTD 2058 Y
Q409 48-03-0372731 PNP KTB 1366 Y
Q403 48-03-0376761 NPN 2SD 1302 R
Q113, 301, 407 48-03-0372751 PNP KTA 1015 Y
Q002, 003,
112, 201-203,
302, 401, 402,
404-406, 902-
904
48-03-026624 NPN 2SC 1815 Y
D1 42-02-0375651 BRIDGE KBPC-25-04
LUG TYPE
DOOl, 002
(1715C)
48-01-0376741 6A2 (1715C)
DOOl, 002
(1707C)
48-01-0376781 IN 5402 (1707C)
DESIGNATOR ALTEC PART
NUMBER
DESCRIPTION
D003-007, 012,
104, 601
48-01-027300 IN 4006
DlOl, 102 48-01-125214U IN 60
D103-108, 201,
202, 301, 401-
403, 602, 603,
901, 902 48-01-122601 IN 4148
D008, 009 48-01-0374001 ZENER UZ-24BM
DOlO, 001, 013 48-01-113386 ZENER UZ-18BM
D203 48-01-0376801 ZENER UZ-5.6BM
POWER LED 39-01-0376811 REC KLR 208 2x5
RED
D903 39-01-0374021 LED SLR-54GG R5
GRE ROHM
CLIP LED,
D904 39-01-0374031 LED SLR-54UR R5
RED ROHM
RLY A 45-01-0376821 RELAY T90N1D12 12-
24
RLY B 45-01-0373941 RELAY RY 24W-K DC
24V
SWITCH 51-02-0376831 SLIDE SSJ622
THERMAL
SWITCH 51-02-0374421 T105 ARIUI
FOOl, 002
(1715C)
51-04-0374381 NB 31.8 mm 4A/250V
UL/CSA (1715C)
FI
(1715C)
51-04-0376841 NB 31.8 mm 6A/250V
UL/CSA (1715C)
FI
(1707C)
51-04-0377281 SB 31.8mm 3A/250V
UL/CSA (1707C)
F2
(17I5C)
51-04-0376851 NB 31.8mm 7A/250V
UL/CSA (17I5C)
F2
(1707C)
51-04-0377291 NB 31.8mm
3.5/V250V UIV CSA
(1707C)
FOOl, 002
(1707C)
51-04-0377341 NB 31.8 mm 2A/250V
UL/CSA (1707C)
SVRIOI, 102 47-06-0374391 SEMI 470B 10/5
SVR601 47-06-0373991 SEMI CS 100KB 10/5
VR901 47-06-0373951 Ф 16 K161 MOO-20KA
15
