Parts List
MODELS 682J & E682L
BUMPER ATTACHMENT
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY.
290-255-081 Bumper Attachment. Includes 6 736-0119 Lockwasher - spring lock, 5/16".. 2
Ref. Mos. 1 through 11)........... 1 7 712-3010 Mut- hex, 5/16"“18...................... 2
1 1910730 Brace - bumper bottom .............. 1 8 1910731 Bumper wraparound.................... 1
2 710-3181 Bolt-hex hd„ 1/2-13x1-1/2".... 1 9 710-0514 Bolt - hex hd., 3/8-16x1".............. 2
3 736-0921 Lockwasher - spring lock, 1/2"... 1 10 736-0169 Lockwasher - spring lock, 3/8".... 2
4 1909748 Spacer, 1/2"................................ 1 11 777S30653 Decal - for bumper...................... 1
5 710-0805 Bolt-hex hd„ 5/16-18x1-1/2".. 2
