Section
6 Parts List
ШНЕЕ18ЯШЕ8/РТ0 DRIVE LEVER & YOKE ASSEMBLY
/ ■
- X N .
1 ^
REF
No.
PART
No.
DESCRIPTION
QTY.
REF
No.
PART
No.
DESCRIPTION
QTY.
1
647-04006
Lever Assembly-Wheels/Tines/
9
GW-2165-2
Yoke-right side............................. .. 1
PTO Drive (Includes Ref. 17)........
1
10
GW-2164
Link-yoke pivot, left & right,
2
1908156
Spring-clutch pawl........................
1
6-7/8" long............................... .. 2
3
710-0805
Bolt-hex hd.. 5/16-18x1-1/2".........
3
11
710-0514
Bolt-hex hd., 3/8-16x1"................ .. 6
4
GW-2447
Bushing-3/8"..
3
12
736-0169
Lockwasher-spring lock, 3/8“........ .. 6
5
1177548
Lockwasher-external tooth, 5/16"
3
13
736-3050
Washer-fiat, 3/8", S.A.E................ .. 6
6
712-3010
IMut-tiex, 5/16"-18.......................
3
15
712-0798
Nut-hex, 3/8"-16.......................... .. 2
7
686-04006
Roller Assembly ..................... .
1
16
1113-1
Bushing-spacer, 19/64“ (.300“)... .. 6
8
GW-2165-1
Yoke-left side................................
1
17
GW-2595
Knob........................................... .. 1
44
