MODELS 682J. E686N & E682L
Parts List
REF
No. PART
No. DESCRIPTION OTY.
REF
No. PART
No. DESCRIPTION QTY.
TRANSMISSION COVER & SHIFT LEVER 35 GW-9301 Key-3/16 sq. x 1"......................... . 3
BRACKET ASSEMBLIES 36 1100004 Bolt-hex hd., 5/16-24x3/4", seif-
1 1186299 Bolt-hex hcl., #10-32x3/8". locking flange, Grade 5.............. 1
self-locking flange...................... 3 37 GW-9944 Washer-disc spring (concave)........ . 1
2 GW-9463 Knob-tines/PTO clutch lever, 38 GW-2107 Pulley-transmission drive, cast iron 1
tapered, plastic.......................... 1 39 GW-50027 Washer-flat, hardened shoulder
3 GW-2124 Detent Plate-tines/PTO clutch lever 1 1-1/4"...................................... . 1
4 777120945 Decal-operating instructions, 40 1186310 Bolt-hex hd,, 1/4-20 x 3/4", front
detent plate............................... 1 bearing cap.............................. . 3
5 1186349 Bolt-flanged hex hd., 42 718-04007 Cap-front bearing......................... . 1
3/8-16x1-1/2“............................ 4 43 721-04044 Seal-oil, front bearing cap............. 1
7 1186329 Bolt-flanged hex hd.. 45 GW-1224-1 Shim-front bearing cap,.
5/16-18x3/4", Grades................ 1 010" thick............................. As Req'd
9 736-0275 Washer-flat, 5/16", S.A.E............... 1 45 GW-1224-2 Shim-as above, .030"................As Req'd
10 GW-2149 Bracket-shift levers........................ 1 45 GW-1224-3 Shim-as above, .005"................ As Req'd
11 GW-9362 Pin-spring, 1/8"............................. 1 45 GW-1224-4 Shim-as above, .062"................ As Req'd
12 GW-9838 Nut-castle (slotted), 1/2"-20, call 46 GW-1714 Bearing & Race
Tech Service for tightening (inci. one bearing GW-9400
instructions................................ 1 and one cup (race) GW-9401).. . 2
13 GW-9934 Washer-shoulder, 1/2"................... 1 47 GW-2655 Shaft-main drive, power unit......... . 1
14 GW-9932 Washer-disc spring........................ 2 48 721-04030 Seal-oi!, drive shaft, rear.............. 1
15 GW-2178 Lever-wheel speed shift................. 1 49 GW-9517 Retaining Ring-(snap ring), internal .....1
16 GW-2523 Cover-power unit transmission.... 1
17 GW-1123 Gasket-transmission cover............. 1 PINION SHAFT ASSEMBLY
18 710-0376 Bolt-hex hd., 5/16-18 x 1", Grade 5, 50 715-0121 Pin-roll (spirol), 1/4 X 2"............... 2
(remoye with care).................... 1 51 718-04006 Plug-retaining, pinion bearing....... 2
19 712-0267 Nut-hex, 5/16--18......................... 1 52 GW-9604 0-Ring-retaining plug.................... 2
20 1901439 Spring-neutral plunger (remove 53 GW-1132-1 Shim-retaining plug, 1-1/64" inner
with care).................................. 1 dia., .033" thick (on right side
21 GW-1035-1 Plunger-neutral (remove with care ) 1 only one GW-1132-1 shim is also
22 1901440 Clip Ring-retains neutral plunger.. 1 used between bearing and washer,
23 1186393 Nut-hex, flange locknut, 3/8“-16... 1 Ref. No.’s 54 & 55)................... . As
24 1902004 Bolt-hex hd., 3/8-16x1-1/2“, Req'd
threaded full length.................... 1 53 GW-1132-2 Shim-same as GW-1132-1, .062" . As
Req’d
TliES/PTO CLUTCH LEVER ASSEMBLY 53 GW-1132-3 Shim-same as GW-1132-1, .010" As
25 786-04002 Lever-eccentric, tines/PTO clutch. 1 Req'd
26 710-3013 Bolt-hex hd., 1/4-20x1/2“.............. 1 54 GW-9404 Bearing-ball, pinion shaft.............. 2
27 741-04008 Bushing-tirtes/PTO clutch lever 55 GW-1126 Washer-pinion shaft...................... 2
eccentric shaft........................... 1 56 GW-1222 Stem Pinion-slow speed gear &
28 GW-9516 Retaining Ring-(snap ring), shaft........................................ . 1
external..................................... 2 57 GW-9502 Ring-retaining, external................ . 1
29 GW-2461 Eccentric-shaft, tines/PTO clutch 58 GW-2656 Worm Gear-bronze, wheel drive.. . 1
lever......................................... 1 59 GW-9300 Key-3/16"x5/8"............................ . 1
30 GW-9911 Lockwasher-hi-collar, 1/4".............. 1 60 GW-1233 Gear-fast speed pinion.................. 1
31 GW-9672 Screw-socket hd., 1/4-20 x 3/8"... 1 (continued on page 55)
DRIVE SHAFT ASSEMBLY
33 716-0101 Retaining Ring-external.................. 1
34 1909139 Dog Clutch-power unit................... 1
51
