MODELS 682J. E686N & E682L
Parts List
REF PART REF PART
No. No. DESCRIPTION QTY. No. No. DESCRIPTION QTY.
WHEEL SPEED LEVER ENGINES AND ENGINE MOUNT
1 GW-9362 Pin-spring, 1/8"................................ 1 28 710-0376 Bolt-hex hd., 5/16-18 x 1", Grade 5..... 2
2 GW-9838 Nut-castle (slotted), 1/2"-20............. 1 29 712-3010 Nut, hex, 5/16-18.......................... .. 1
3 GW-9934 Washer-shoulder, 1/2"...................... 1 30 GW-1034 Bar-engine mounting..................... .. 2
4 GW-9932 Washer-disc spring........................... 2 31 GW-9147 Plug-thread protector, red plastic. .. 2
5 GW-2178 Lever-wheel speed shift.................... 1 32 GW-9572 Bolt-hex hd., 5/16-24x1-1/8".......... .. 4
6 1902240 Knob-wheel speed shift lever............ 1 33 736-0119 Lockwasher-spring lock, 5/16"........ .. 4
7 GW-9317 Pin-cotter, 3/32" X 1“....................... 1 34 GW-2553 Mount-engine to tiller..................... .. 1
8 GW-1515 Connecting rod, wheel speed -shift 36 736-3052 Washer, fiat, .406 x 1.0 x ,105....... .. 1
lever (Inch Ref. 7 & Ref. 9)............ 1 - 777S30647 Decal-hot surface warning............. .. 1
9
10
GW-1033
736-0275 Swivel-connecting rod.......................
Washer-fiat, 5/16", S.A.E.................. 1
1
43
WHEEL & TIRE ASSEMBLIES
.. 2
11 GW-9338 Pin-hair cotter.................................. 1
1915072 Pin- roil, 5/16" X 1-1/2".................
12
13 712-0158
710-0514 Locknut-hex hd., 5/16"-18................
Bolt-flanged hex hd,, 3/8-16 x 1"...... 1
5
45 1915056 Wheel & Tire Assy- Left-Hand bar
tread, left side, 4:80 x 8" tubeless tire
14 736-0169 Lockwasher-spring lock. 3/8"............ 5
with valve stem, on one-piece
steel wheel................................ .. 1
15 736-3050 Washer-flat, 3/8", S.A.E.................... 8
45A 1915057
17 GW-1113-1 Bushing-spacer, 19/64" (.300"lg.).... 4
Wheel & Tire Assy - Right-Hand bar
18 GW-9120 Ring-retaining (tolerance ring).......... 1
tread. Same as above but for right side
of tiller______________________ 1
BELT DRIVE SYSTEM 46 1902020 Cap-wheel hub.............................. .. 2
19 GW-2102 Block- belt adjustment, 3-7/8"........... 1
20 GW-2100 Rod- belt adjust.. T" with
measuring gauge.......................... 1
21 777120942 Decal- engine stabilization................ 1
22 1100012 Bolt-hex hd.. 3/8-24x1-1/2".............. 1
23 GW-2111 Disc-reverse..................................... 1
24 GW-9245 Belt-forward drive (no substitute
due to extra strength required)...... 1
25 GW-1483 Pulley-engine power take off............. 1
26 GW-1138-1 Shim-engine pulley, 1/16" As Req'd
26 GW-1138-2 Shim-as above, 1/32" As Req'd
27 GW-9303 Key-engine pulley, 3/16"sq. x 2-1/2" 1
Contact an authorized engine dealer. Troy-Bilt dealer or the Factory for replacement engine
information.
Contact an authorized engine dealer for engine service or parts. Refer to the engine name­
plate for engine model and type information.
For correct traction and directional control, Bar Tread Tires should be mounted on the
tiller so the closed end of the “V” in the tire tread on top of the tire faces forward.
49
