MODELS E686N & E682L
Parts List
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY.
1 GW-96515 Cable-battery, positive and negative 14 GW-96514 Solenoid-starter, includes nuts and
terminals.................................. 2 washers for cables and wires... 1
2 GW-97020 Boot-terminal insulating................ 3 15 736-0119 Lockwasher-5/16"........................ 3
3 GW-9552 Screw-self-threading, 16 1186211 Nut-hex, 5/16"-24........................ 2
1/4-20x1/2"............................. 3 17 736-0147 Lockwasher-external tooth, #10.. 1
4 1186309 Bolt-hex hd., 1/4-20x5/8"............. 2 18 GW-9853 Nut-hex, #10-32,......................... 1
5 1901894 Wire-recharge (red)..................... 1 19 GW-96510 Cable-solenoid to starter motor.. 1
6 GW-2614 Battery Hold-down Clamp-with 20 GW-2557 Battery Bracket............................ 1
attached Key Switch Plate......... 1 21 1186349 Bolt-flanged hex hd.,
7 777S30648 Decal-ignition switch instruc......... 1 3/8-16x1-1/2“........................... 2
8 725=0267 Key Switch-includes two 23 GW-9265 Tie-plastic, wire retaining.............. 1
ignition keys (Ref. No. 9), one 27 725-0157 Tie-plastic.................................... 2
lockwasher, and one mounting 28 1908118 Wire Harness & Connecting
nut (lock-washer and nut not Terminal Assembly.................... 1
available separately)................. 1 29 712-3010 Nut-flange lock, 5/16"-18............. 1
9 725-0201 Key-ignition, one pair................... 1 30 1186389 Locknut-hex, 1/4"-20................... 3
10 1186073 Bolt-carriage, 1/4-20 x 1-1/4"....... 2 31 629-04018 Ground Wire Assembly................. 1
11 1100241 Lockwasher-spring lock, 1/4"........ 2 32 1901202 Cable-ground, solenoid to engine
12 712-3006 Nut-hex, 1/4--20.......................... 2 block........................................ 1
13 725-1706A Battery-12 volt, 270 CCA.............. 1 33 710-3180 Bolt-flange lock, 5/16-18 x 1"....... 1
