MODELS 682J & E682L
Parts List
REF
Mo.
PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY.
1 1915068 Screw-self-sealing,1/4"-20 x 5/8" 5 17 GW-1224-3 Shim-same as above, .005" As
2 GW-20873 Cover-tiller housing...................... 1 thick......................................... .Req'cl
4 711-04082 Shaft-tiller tine............................. 1 17 GW-1224-4 Shim-same as above, .062” As
5 741-3037 Ball Bearing................................. 2 thick......................................... .Req'd
6 1901976 Worm Gear-bronze, tiller tine 18 GW-1714 Bearing & Race............................ . 2
shaft........................................ 1 (inch one bearing GW-9400
7 GW-1104 Key-tiller tine shaft, woodruff key 1 and one cup (race) GW-9401)
8 721-04035 Seal-oil, tiller tine shaft................. 2 19 GW-2653 Shaft-main tiller drive................... . 1
20 721-04030 Seal-oil, drive shaft, front.............. . 1
TILLER DRIVE SHAFT ASSEMBLY 21 GW-9517 Retaining Ring-internal................. . 1
9 716-0101 Retaining Ring-external................ 2
10 1909138 Dog Clutch-tiller drive shaft........... 1 TRANSilSSiON HOUSING AND DIPSTICK
11 GW-9301 Key-3/16"x1"............................... 1 23 1901971 Housing-tiller attachment (Empty
12 GW-2127 Spring-dog clutch......................... 1 housing without shafts, gears, seals,
13 GW-1138-1 Shim-dog clutch, 1/16"(.62") thick. 1 dipstick, etc.)............................... . 1
14 1915069 Screw-self-sealing,1/4"-20 x 7/8" 3 24 1909157 Dipstick-oil, tiller attachment......... . 1
15 GW-1115 Cap-rear bearing.......................... 1 TRAiSlISSIOi ASSEMBLY
17 GW-1224-1 Shim-front bearing cap, .010" As
—
618-04003 Transmission -Tiller
thick......................................... Req'd (Includes Ref. 1-24).................. . 1
17 GW-1224-2 Shim-same as above, .030" As
thick......................................... Req^d
55
