MODEL 931014 MANUAL LIFT & LINKAGE ASSEMBLY PARTS LIST
REF
NO
PART
NO
DESCRIPTION
NO
REQ'D
REF
NO
PART
NO
DESCRIPTION
NO
REQ'D
1
031759
LIFT HANDLE
1
26
067004
COTTER PIN
1
2
031760
PLUNGER
1
27
062005
CARRIAGE BOLT 3/8 x 2-1/4
4
3
058034
PIN, Roll 1/8"
X
3/4"
1
28
031764
QUADRANT
1
4
064096
WASHER, Special
1
29
062010
BOLT, Carriage 3/8-16x3/4
2
5
083104
SPRING
1
30
063021
LOCKWASHER
2
6
055057
BUSHING SLEEVE
2
31
065018
NUT
2
7
031775
PIN
1
32
031748
LATCH ROD-Model 931011
1
8
064127
WASHER
2
33
065001
NUT, Jam
1
9
067003
COTTER PIN
1
34
075052
KNOB
1
10
031761
LATCH
1
35
031747
LATCH
1
11
062050
CARRIAGE BOLT, 3/8-16 x 2-3/4
1
36
083105
COMPRESSION SPRING
4
12
065039
LOCKNUT
1
37
064043
WASHER
4
13
066022
KEY, Straight
1
38
067024
COTTER PIN
2
14
031745
ARM
1
39
031015
FRONT ROCK SHAFT, Connector Link
1
15
064160
WASHER, Special
1
40
064009
WASHER
1
16
031757
ARM
1
41
067029
PIN, Hair Cotter
1
17
031758
ARM
1
42
067006
COTTER PIN
1
18
031746
CENTER LIFT LINK
1
43
065042
LOCKNUT, 5/16-18
1
19
031729
REAR LIFT LINK
1
44
059022
CAPSCREW, 5/16-18x3/4
1
20
067026
COTTER PIN
2
45
067026
COTTER PIN
2
21
031017
CHAIN
2
46
531005
FRONT ROCK SHAFT
1
22
083107
SPRING
2
47
029011
BLOCK
4
23
031753
SPRING CLIP
1
48
031014
BRACE
4
24
031813
STRAP
1
49
059134
CAP SCREW, 5/16-18
X
1-1/4 Gr. 5
1
25
031051
CLEVIS PIN
1
50
063003
LOCKWASHER
1
51
064115
SHIM, .005 Thick
AR
52
055021
FLANGED BUSHING
1
2 7 -
