HOOD, GRILL, HEADLIGHTS AND HEAT SHIELD
GEAR MODELS 931013 & 931014
^
M)
(22
------- ^
---- (j?)
REF
NO.
PART
NO.
DESCRIPTION
NO.
RED'D.
REF
NO.
PART
NO.
DESCRIPTION
NO.
REO'D.
1
531056
HO0D,S-10G
1
20
064008
WASHER, Flat, 3/8"
6
531055
H00D,S-14G
1
21
062032
BOLT, Carriage 3/8" x 2
2
4
031046
GRILL
1
22
062013
BOLT, Carriage, 3/8" x 1 ■
6
5
031139
SIDE, Right Hand
1
23
063021
LOCKWASHER, 3/8"
8
6
031138
SIDE, Left Hand
1
24
065018
NUT, Hex, 3/8"
8
7
031185
HINGE, Right Hand
1
25
061042
SCREW, Machine, Truss H, 5/16 x 3/4
2
8
031186
HINGE, Left Hand
1
26
064123
WASHER, Flat, 5/16"
2
9
031145
SPACER, 3/4"
2
29
075058
HOOD STOP
2
10
075064
GROMMET
2
30
063018
STAR LOCKWASHER
2
11
031986
MUFFLER SHIELD, S-10G .S-14G
1
12
075066
GROMMET
1
13
069094
"J” CLAMP
2
14
031093
LATCH
1
15
061039
SCREW, Machine, Truss H, 1/4 X 3/4
5
16
064127
WASHER, Flat, 1/4"
5
17
063002
LOCKWASHER, 1/4"
5
18
065032
NUT, Hex, 1/4"
5
