REAR BRAKE & CLUTCH ASSEMBLY PARTS
GEAR MODELS 931013 & 931014
REF
N0.
PART
N0
DESCRIPTION
NO
REQ'D
931014 931013
REF
NO.
PART
NO
DESCRIPTION
NO
REQ'D
931014 931013
1
031679
TORQUE, Spider
2
2
33
062013
BOLT, Carriage 3/8" x 1"
4
4
2
031678
DUST SHIELD
2
2
34
067006
PIN, Cotter 3/16"
X
1-1/4"
1
1
3
531039
BRAKE SHOE (sold in sets of two only) 2
2
35
031791
L.H. PEDAL
1
4
031680
PIVOT NUT
2
2
031762
L.H. PEDAL
1
5
031682
SOCKET, Adjusting Screw
2
2
36
069113
CLUTCH CABLE
1
1
6
083162
SPRING, Adjusting Shoe
2
2
37
031674
BRAKE DRUM
2
2
7
083161
SPRING', Shoe Return, L.H.
2
2
38
083122
SPRING
2
2
8
083160
SPRING,Shoe Return, R.H.
2
2
39
013303
CLEVIS PIN
2
2
9
031763
CLUTCH ARM
1
1
40
065018
NUT, Hex 3/8"
5
5
10
031681
ADJUSTING SCREW, (star wheel)
2
2
41
063021
LOCKWASHER,3/8"
1
1
11
067032
HAIR PIN RETAINER
4
4
42
075051
PEDAL PAD
2
2
12
031675
STRUTS. LEVER ASSEMBLY
2
2
43
059030
CAP SCREW, HH 3/8"
X
2-1/4"
1
1
13
031677
PIN
2
2
44
031505
ARM, Brake
1
1
14
064156
WAVE WASHER
2
2
45
058003
ROLL PIN
1
1
15
031702
RETAINER CLIP
2
2
46
059135
CAP SCREW, 5/16-18x3/4
1
1
16
067001
PIN,Cotter3/32"x3/4"
7
7
47
075055
GROMMET
2
2
17
031507
BRAKE LATCH
1
48
055095
BUSHING
1
1
18
059001
CAPSCREW, HH, 1/4"
X
3/4"
1
1
49
064002
WASHER, 5/16"
1
2
19
064127
WASHER, Special
1
1
50
031504
R.H. PEDAL
1
1
20
011091
SPACER, Bushing
1
1
51
065042
LDCKNUT, Hex 5/16"
3
4
21
065040
LOCKNUT, Hex, 1/4"
1
52
025135
SPACER
1
2
22
031935
ROD
2
2
53
031936
BAL. LINK
1
1
23
031939
ARM
1
1
54
074046
FLANGE WHIZLDCKSCREW
8
8
24
031940
ARM
1
1
55
031676
PARK BRAKE LEVER
2
2
25
031938
BRAKE ARM
2
2
56
064057
WASHER, 5/16"
2
2
26
031808
BRAKE ROD
1
1
58
064043
WASHER
7
7
27
064048
WASHER, Flat 3/8"
1
1
59
055095
BUSHING
2
28
058040
PIN, Drive 1/4"
X
1-1/4"
2
2
055096
BUSHING
1
29
031941
BRAKE SHAFT
1
1
60
064062
WASHER
AR
AR
30
031509
PLATE
2
2
61
631107
R.H. BRAKE ASSEMBLY
1
1
31
059003
CAPSCREW, HH 5/16"
1
2
631108
L.H.BRAKE ASSEMBLY
1
1
32
063004
LOCKWASHER,3/8"
4
4
62
031937
CLIP
1
1
