MAIN DRIVE
GEAR MODELS 931013 & 931014
REF
NO.
FART
NO.
DESCRIPTION
NO
REQ'D
REF
NO.
PART
NO.
DESCRIPTION
NO
REQ'D
1
* TRANSAXLE
1
41
059099
CAP SCREW, HH, 3/8-16 x 5/8 Grade 5
4
2
* T-DRIVE HEAD ASSEMBLY
1
42
065115
LOCKNUT
2
3
031771
BRACKET
1
43
083120
COMPRESSION SPRING
2
4
031821
STRAP
1
44
059068
CAP SCREW, 3/18-16x2
1
5
031766
SUPPORT -L.H. Axle
1
45
057012
SNAPPING EXTENSION
1
6
031685
SUPPORT - R.H. Axle
1
46
065120
NUT, Hex Jam
2
7
031728
WHEEL HUB
2
47
069094
J- Clamp
1
8
062028
BOLT, Carriage 3/8-16 x 1 Gr. 5
1
48
063003
LOCKWASHER,5/16
3
9
064043
WASHER
1
49
066030
KEY,Woodruff 1/4"
X
1-1/8"
2
10
060032
SETSCREW
2
51
066003
KEY, Woodruff No. 9
2
11
083168
SPRING EXT.
2
52
059151
CAP SCREW, 3/8-16
X
1-1/2" GR 5
4
12
031956
BRACKET
1
53
065039
LOCKNUT
1
13
031958
ROD
1
54
070044
LUG BOLT
10
14
031743
IDLER ARM
1
55
070031
SCREW, Whiziock
3
15
031755
BELT FINGER
3
56
064003
WASHER
5
16
031735
BRACKET
57
058009
ROLL PIN, 1/8x1
2
17
031957
BELL CRANK
1
58
059028
CARRIAGE BOLT 5/16x3/4
1
18
031773
BELL CRANK
1
59
064007
WASHER, 1/4 Standard
2
19
031793
ROD
1
60
031949
BELT FINGER MOUNT
1
20
031772
SHEAVE
1
62
064002
WASHER
2
21
031742
SHEAVE
1
63
067024
COTTER PIN, 1/8
X
3/4
4
22
031744
IDLER PIN
1
64
062047
BOLT, Carriage 1/2-13 x 1-1/4 GR5
4 '
23
631002
TIRE 8i WHEEL ASSEMBLY S-14G
2
65
065127
LOCKNUT, 1/2-13 GRC
4
071105
TIRE, 23x 10.50x 12
2
66
062015
BOLT, Carriage 5/16-18 x 1
1
071106
WHEEL RIM W/Valve
2
67
065042
LOCKNUT
7
23
631097
TIRE & WHEEL ASSEMBLY S-10G only
2
68
062016
BOLT, Carriage
2
071114
TIRE, 23x8.50x 12
2
70
065039
LOCKNUT, 3/16
3 1
071115
WHEEL RIM
2
71
066014
KEY, Woodruff No. 61
1
26
059135
CAPSCREW, 5/16-18x3/4
1
72
067004
PIN COTTER, 5/32x1
1
27
072090
V-BELT, Matched Set
1
73
064008
WASHER 3/8
1
28
073055
IDLER
1
74
065114
LUG NUT
10 1
29
O6504O
LOCKNUT
2
75
067016
COTTER PIN
1
30
059022
CAP SCREW, HH. 5/16-18x3/4
8
76
031755
BELT FINGER
1
31
031953
COUPLING, Input
1
77
065061
JAM NUT
3
33
064002
W
asher
, Flat 5/16"
8
78
003086
BALL JOINT
2
34
031952
SPACER.COUPLING
2
79
063021
LOCKWASHER 3/8"
4
35
531093
DRIVE SHAFT ASSEMBLY, W/Roll Pin
1
80
064164
WASHER, .805/.842x2x 16 Ga.
1
37
031978
DRIVE COUPLING
1
81
065122
LOCKNUT, 3/8-16 GRC
4
38
062010
BOLT, Carriage 3/8-16 x 34
3
82
067021
COTTER PIN, 1/8
X
1-1/2
1
39
065053
LOCKNUT, 3/4"
3
40
059001
CAP SCREW
2
*See Y6ur Nearest Tecumseh Service Central For Repairs
Tec. Model No. 2335 Transaxle
Tec. Model No. 3179-P91 T-Drive Head Assy.
