D e s c r i p t i o n l
2 - 7
S p e c i f i c a t i o n s : H T C f o r H o t A i r D r y e r s ( H A D )
A
B
C
D
E
F
H
G
I
2
Description
MODEL HTC
HTC-30B*
HTC-30A*
HTC-60A*
HTC-90A*
HTC-120A*
HTC-180A*
Hot air dryer mode
l
600 800
1000
1600
2400
3200
5000
Performance characteristics
Temperature range
120° - 250° F {49° - 121° C}
Flow rate cfm
300 400
500
800
1200
1600
2500
Pressure drop@flow rate
inches WC
†
3.0 5.0
3.2
5.4
6.1
6.4
8.0
{mm} WC
†
{76.2} {127}
{81.2}
{137.2}
{155.0}
{163.0}
{203.2}
Dimensions inches {cm} and weight lb {kg}
Heater box dimensions
Inlet size (OD)
5
5
8
8
8
12
Outlet size selection (OD)
5
5
8
8
8
12
A - Height
31.4 {79.8}
27.5 {69.9}
27.5 {69.9}
32.0 {81.3}
31.0 {79.0}
34.0 {86.3}
B - Width
10.1 {25.7}
13.6 {34.5}
13.6 {34.5}
15.9 {40.4}
16.0 {40.6}
18.0 {45.7}
C - Depth
10.7 {27.2}
10.7 {27.2}
10.9 {28.0}
16.0 {40.6}
17.0 {43.2}
20.0 {50.8}
D - Height of discharge
0 {0}
5.9 {15.0}
2.0 {5.1}
1.0 {2.5}
2.0 {5.1}
1.0 {2.5}
nozzle above heater box
E - Height of inlet nozzle
below the heater box
8.0 {20.3}
11.4 {30.0}
8.0 {20.3}
11.0 {27.9}
13.0 {33.0}
13.0 {33.0}
Installed weight lb {kg}
37 {17}
58 {26}
78 {35}
93 {42}
102 {46}
131 {59}
Control center dimensions
F - Height
24.0 {61.0}
24.0 {61.0}
24.0 {61.0}
36.0 {91.4}
48.0 {122.0}
60.0 {152.4}
G - Width
24.0 {61.0}
24.0 {61.0}
24.0 {61.0}
30.0 {76.2}
36.0 {91.4}
42.0 {106.7}
H - Depth
10.0 {25.4}
10.0 {25.4}
10.0 {25.4}
10.0 {25.4}
10.0 {25.4}
12.0 {30.5}
I - Clearance for heat sink
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
Installed weight lb {kg}
150.0 {68.0}
150.0 {68.0}
150.0 {68.0}
180.0 {81.6} 250.0 {113.0}
consult Conair
Voltage Current Amps
400V/3 phase/50-60 Hz
43.3
43.3
86.6
129.9
173.2
259.8
460 V/3 phase/50-60 Hz
37.7
37.7
75.4
113.1
150.8
226.2
575 V/3 phase/50-60 Hz
30.1
30.1
60.2
90.3
120.4
180.6
SPECIFICATION NOTES:
*
The HTC model number reflects the kilowatts of each unit. For example, HTC-60 has a 60 kilowatt heater.
†
The unit of measure WC is water column.
Specifications may change without notice. Consult a Conair representative for the most current information.
TPDS024-0106
