Conair Hopper Temperature Controller UGD031 User Manual
Page 18
S p e c i f i c a t i o n s : H T C M O D E L S 6 0 0 - 5 0 0 0
2 - 6
l D e s c r i p t i o n
A
B
C
D
E
F
G
I
MODEL HTC
HTC-30H*
HTC-60H*
HTC-90H*
HTC-120H*
HTC-180H*
HTC-270H*
Carousel Plus dryer mode
l
W600
W800 W1000
W1600
W2400
W3200
W5000
Performance characteristics
Temperature range
150° - 375° F {66° - 191° C}
Flow rate cfm
300
400
500
800
1200
1600
2500
Pressure drop@flow rate
inches WC
†
3.0
1.8 2.3
4.0
3.8
5.9
6.4
{mm} WC
†
{76.2}
{45.7} {58.4}
{101.6}
{96.5}
{149.9}
{162.6}
Dimensions inches {cm} and weight lb {kg}
Heater box dimensions
Inlet size (OD)
8
8
12
12
12
12
Outlet size selection (OD)
8
8
12
12
12
12
A - Height
31.4 {79.8}
27.5 {69.9}
27.0 {68.6}
31.0 {78.7}
34.0 {86.4}
36.4 {92.5}
B - Width
10.1 {25.7}
13.6 {34.5}
16.0 {40.6}
16.0 {40.6}
18.0 {45.7}
24.2 {61.5}
C - Depth
10.7 {27.2}
10.9 {27.7}
10.9 {27.7}
16.0 {40.6}
17.0 {43.2}
17 {43.2}
D - Height of discharge
1.75
1.5
2.0
1.0
2.0
1.0
nozzle above the heater box
{4.4}
{3.8}
{5.1}
{2.5}
{5.1}
{2.5}
E - Height of inlet nozzle
10.6
7.1
8
10
13
15.4
below the heater box
{26.9}
{18.0}
{20.3}
{25.4}
{33.0}
{39.1}
Installed weight lb {kg}
‡
38 {17}
37 {17}
78 {35}
93 {43}
102 {46}
131 {59}
Control center dimensions
Height - F
24.0 {61.0}
24.0 {61.0}
36.0 {91.4}
48.0 {122.0} 60.0 {152.4}
60.0 {152.4}
Width - G
24.0 {61.0}
24.0 {61.0}
30.0 {76.2}
36.0 {91.4}
42.0 {106.7}
42.0 {106.7}
Depth - H
10.0 {25.4}
10.0 {25.4}
10.0 {25.4}
10.0 {25.4}
12.0 {30.5}
12.0 {30.5}
Clearance for heat sink - I
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
3.0 {7.6}
Installed weight lb {kg}
150.0 {68.0}
150.0 {68.0}
180.0 {81.6}
250.0 {113.0}
consult Conair
consult Conair
Voltage Full Load Amps
400 V/3 phase/50-60 Hz
43.3
86.6
129.9
173.2
259.8
389.7
480 V/3 phase/50-60 Hz
37.7
75.4
113.1
150.8
226.2
339.3
575 V/3 phase/50-60 Hz
30.1
60.2
90.3
120.4
180.6
270.0
SPECIFICATION NOTES:
*
The HTC model number reflects the kilowatts of each unit. For example, HTC-60 has a 60 kilowatt heater.
†
The unit of measure WC is water column.
‡
Weights are approximate.
Specifications may change without notice. Consult a Conair representative for the most current information.
TPDS022-0106
