Details of the machine
22
21
12
20
19
18
24
16
17
15
Details of the machine
1 Loopercover
2 Looper cover opening indent
3 Knife guard
4 Cloth plate
5 Stitch plate
6 Presser foot
7 Lower looper tension dial
8 Upper looper tension dial
9 Right needle tension dial
10 Left needle tension dial
11 Thread take up cover
12 Thread guide plate
13 Accessory box
14 Bulb cover
15 Power/light switch
16 Handwheel
17 Machine socket
18 Thread stand
19 Anti-vibration cone
20 Spool holder pin
21 Retractable support rod
22 Open thread guide
23 Presser foot lifter
24 Stitch length dial
25 Differentia! feed dial
