SINGER 1200 Athena User Manual
Page 20
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Hepiacing a
Wound
Bobbin
Raise needie and take-up iever to its highest
position by turning hand wheel toward you.
A. Open slide plate; move bobbin latch to left.
B. Draw about an inch (2.5cm) of thread from
bobbin and insert bobbin in case. Move
bobbin latch slightly to the right (sewing
position).
C. Puli thread into bobbin-case slot (1), draw
it under flat spring and around to and past
point
(
2
)
leaving three inches (7cm) of free
thread.
D.
Close slide plate. Closing slide plate
makes
raising
bobbin
thread
easier
because this step prevents the thread from
coming out of the threading points.
■Replacing aiWoéml Bobbin
Flat Spring:
Draw Thread ■
i^roind fas t|Po I |t (iil
