SEPARATE VHP (75-OHM) / UHF (300-OHM) ANTENNA

(1) Disconncci the VHF coaxial anlcnna cable and the

UHF flat twin-lead antenna cable from the back of
your TV set.

(2) Reconnect those cables to a UHF/VHF combiner

(not supplied).

(3) Connect end of the UHF/VHF combiner to the ANT.

IN terminal of the VCR.

(4) Connect one end of the COAXIAL CABLt (sup

plied) to the ANT. OUT terminal of the VCR.

(5) Connect the other end of the COAXIAL CABLE

(supplied) to a UHF/VHF separator (not supplied).

(6) Connect the separator’s coaxial end to the TV’s

VHF jack, and flat twin-lead end to the TV’s UHF
terminal.

INDOOR VH^/UHE ANTENNA

(J)Uisconnccl

the

indoor

VHF/UHF

anlcniia cable (3)Connect one end

of the COAXIAL CABLL (sup-

from the back of your TV set.

plied) to the ANT. OUT terminal of the VCR.

(2)Reconnect the cable to the ANT. IN terminal of the (4)Connect the other end of the COAXIAL CABLE

VCR.

(supplied) to the antenna/cable jack of your TV.

NOTE: The connection of an indoor antenna to a VCR may not always give acceptable TV Reception.
