CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number in all correspondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE J
KEY
NO.
PART
NUMBER DESCRIPTION QUAN.
1 607818-002 Sleeve Bearing............................................................................................................. .................................... 1
2 990908-009 * Screw (6-19 X 5/8 in. Pan Hd.)....................................................................................... .................................... 4
3 976450-001 Gear Case Cover......................................................................................................... .................................... 1
4 STD511005 * Screw (10-24 X 1/2 in. Pan Hd.).................................................................................... .................................... 1
5 662029-001 Washer......................................................................................................................... .................................... 1
6 977215-001 Spring........................................................................................................................... .................................... 1
7 976416-001 Pulley Shaft Assembly................................................................................................. .................................... 1
8 644186-002 Sleeve Bearing (Flange).............................................................................................. .................................... 2
9 976414-001 Worm Gear Assembly.................................................................................................. .................................... 1
10 706239-830 Washer......................................................................................................................... .................................... 1
11 090403-080 Screw (M3 X 8 Pan Hd.)................................................................................................ .................................... 2
12 976411-001 Gear Case.................................................................................................................... .................................... 1
13 976412-001 Motor Assembly........................................................................................................... .................................... 1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
>
