CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE E
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 622210-043 * Screw (10-32 X 5/8 in. Rd. Hd.) ...................................... ............. 4
2 976323-001 Track................................................................................ ............. 2
3 976326-002 Arm.................................................................................. ............. 1
4 980613-001 Support Bracket.............................................................. ............. 1
5 611114-002 * Screw (10-32 X 1/2 in. Flat Head T. C.).......................... ............. 1
6 706382-834 Washer............................................................................ ............. 2
7 980455-001 * Screw (1/4-20 x 5/8 in. Self Tapping Hex Washer Hd.)... ............. 6
8 641180-005 Push Nut (3/8 in.)............................................................ ............. 2
9 976321-001 Clevis Pin........................................................................ ............. 1
10 976804-001 Arm Lock Rod Assembly................................................. ............. 1
11 976314-001 Guide............................................................................... ............. 1
12 976312-001 Arm Lock Pawl................................................................ ............. 1
13 976313-001 Tension Spring................................................................ ............. 1
14 976310-001 Pin Housing..................................................................... ............. 1
15 976311-001 Arm Index Pin.................................................................. ............. 2
16 976315-001 Index Rod........................................................................ ............. 1
17 976316-001 Arm Lock Spring.............................................................. ............. 1
18 ** STD541110 * Hex Nut (10-32)............................................................... ............. 1
19 618375-000 Arm Knob Lever (Left Hand)........................................... ............. 1
20 976827-001 Arm Lock Lever Assembly.............................................. ............. 1
21 618376-000 Arm Knob Lever (Right Hand)......................................... ............. 1
22 931055-006 Washer............................................................................ ............. 1
23 606066-011 * Screw (10-32 X 2-1/4 in. Pan Hd.).................................... ............. 1
24 641180-006 Push Nut (1/4 in.)............................................................ ............. 1
25 931744-059 * Washer (1/4 in.)............................................................... ............. 1
26 976319-001 Lever Pin......................................................................... ............. 1
27 976320-001 Pin................................................................................... ............. 1
28 976322-001 Arm Insulation................................................................. ............. 1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
