CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE F
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 980548-001 Carriage Lock Label................................................... .................. 1
2 618488-000 Carriage Lock Knob................................................... .................. 1
3 ** STD511105 * Screw (10-32 X 1/2 in. Pan Hd.)................................. .................. 4
4 976287-001 Carriage Cover (LH)................................................... ..................1
5 976348-001 Rip Scale Indicator..................................................... .................. 2
6 ** STD510606 * Screw (6-32 X 5/8 in. Pan Hd.)................................... .................. 4
7 976352-001 Speed Nut.................................................................. .................. 2
8 976409-001 Swivel Latch Spring................................................... .................. 1
9 976286-002 Carriage...................................................................... .................. 1
10 976831-001 Thrust Washer............................................................ .................. 8
11 976285-001 Carriage Bearing........................................................ ..................4
12 976337-001 Washer....................................................................... .................. 4
13 976349-001 Eccentric Screw......................................................... .................. 2
14 976350-001 Rip Lock Shoe............................................................ .................. 1
15 976353-001 Bumper....................................................................... .................. 2
16 976278-001 Yoke Clamp Stud Assembly...................................... .................. 1
17 999982-001 Washer....................................................................... .................. 2
18 ** STD541462 * Lock Nut (5/8-11)........................................................ .................. 1
19 976385-001 Sleeve Bearing........................................................... .................. 2
20 620074-001 * Bolt (5/16-18x1 -1 /2 in. Hex Hd.)............................... .................. 2
21 615570-020 * Bolt (5/16-18x3/4 in. HexHd.) .................................... .................. 2
22 ** STD551231 * Lock Washer (5/16)..................................................... .................. 2
23 624088-002 * Washer........................................................................ .................. 2
24 976345-001 Spring Bracket............................................................ .................. 1
25 976771-001 Index Spring............................................................... .................. 1
26 976346-001 Yoke Pivot Latch........................................................ .................. 1
27 976288-001 Carriage Cover (RH).................................................. .................. 1
28 976347-002 Index Pin Housing...................................................... .................. 1
29 624282-002 * Square Nut (5/16-18).................................................. .................. 2
30 ** STD541031 * Hex Nut (5/16-18)....................................................... .................. 4
31 980538-001 Yoke Lock Label......................................................... .................. 1
32 976472-001 Yoke Lock Handle (Includes Key No. 31).................. ..................1
33 980524-001 Switch Label............................................................... .................. 1
34 980526-001 Warning Label............................................................ .................. 1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
__ *
7 5 CRflFTSMfir RADIAL SAW 315.220100
