CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number in all correspondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE 1
KEY PART KEY PART
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER DESCRIPTION QUAN.
1 976366-001 Guard Screw (10-24 Slotted)............ ...........1 17 977246-001 Guard Knob........................................ .......... 2
2 977237-001 Inner Lower Guard............................ ...........2 18 706382-041 Washer............................................... .......... 2
3 976370-002 Shoulder Screw (1/4-20 Button Hd.). ........... 2 19 977254-001 Spacer................................................ .......... 1
4 979528-001 Guard Nut (10-24)............................. ........... 1 20 977240-001 Riving Knife........................................ .......... 1
5 641180-003 * Push Nut (1/4 in.)............................... ...........1 21 977239-001 Anti-Kickback Bracket........................ .......... 1
6 977244-001 Knife Support.................................... ........... 1 22 641180-004 * Push Nut (5/16 in.).............................. .......... 2
7 621032-009 * Star Washer (1/4 in.)......................... ........... 1 23 976879-002 Upper Guard...................................... .......... 1
8 977478-001 Slotted Nut........................................ ........... 1 24 977480-003 * Bolt (5/16-18 X 1-3/4 in. Rd. Hd.) ........ ..........1
9 ** STD541425 * Lock Nut (1/4-20)............................... ...........1 25 ** STD533106 * Bolt (5/16-18 X 5/8 in. Rd. Hd.)............ .......... 1
10 931744-059 * Washer (1/4 in.) ................................ ........... 2 26 977225-001 Square Nut......................................... .......... 1
11 977243-001 Anti-Kickback Pawl............................ ........... 4 27 977224-001 Guard Clamp Screw........................... .......... 1
12 977253-001 Bushing............................................. ........... 2 28 977223-001 Dust Guide......................................... ..........1
13 ** STD512510 * Screw (1/4-20 x 1 in. Pan Hd.).......... ........... 1 29 977238-001 Hold Down Guard.............................. .......... 1
14 980498-001 Outer Lower Guard Assembly........... ........... 1 30 977230-001 Upper Guard Retainer Assembly....... .......... 1
15 976370-001 Shoulder Screw (1/4-20 Button Hd.). ...........2 31 622210-041 * Screw (1/4-20 x 9/16 in. Flat Hd. T. F.)...........4
16 706382-327 Washer.............................................. ........... 2 32 977480-001 * Bolt (1/4-20x5/8 in. Rd. Hd. ).............. ..........1
* Standard Hardware Item -- May Be Purchased Locally
** Available From Div. 98 — Source 980.00
