CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE D
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 618235-000 Data Plate................................................................... .................. 1
2 618233-000 Base Assembly.......................................................... .................. 1
3 976386-001 * Screw (5/16-18 X 3/4 in. Hex Washer Hd.).................. .................. 2
4 976296-001 Elevation Nut.............................................................. .................. 1
5 976294-001 Column Assembly...................................................... .................. 1
6 976293-001 Retaining Ring............................................................ .................. 1
7 976292-001 Arm Latch................................................................... .................. 1
8 ** STD503705 * Setscrew (3/8-16 x 1/2 in. Soc. Hd.)........................... .................. 3
9 ** STD541031 * Hex Nut (5/16-18)....................................................... ................17
10 977492-001 * Locking Cap Screw (1/4-20 x 5/8 in.)......................... .................. 2
11 976289-002 Support (LH)............................................................... .................. 1
12 976295-001 Column Tube GIB....................................................... .................. 2
13 976833-001 Elevating Shaft Assembly.......................................... .................. 1
14 976290-002 Support (RH).............................................................. .................. 1
15 615570-022 * Bolt (5/16-18x2 in. Hex Hd.)....................................... ................ 12
16 615570-021 * Bolt (5/16-18x2 in. Hex Hd.)....................................... .................. 2
17 ** STD523712 * Bolt (3/8-16 X 1-1/4 in. Hex Hd.).................................. .................. 4
18 617264-001 * Washer (3/8 in.).......................................................... .................. 8
19 615570-020 * Bolt (5/16-18x3/4 in. HexHd.) .................................... .................. 2
20 ** STD551137 * Lock Washer (3/8)....................................................... .................. 4
21 615570-007 * Bolt (5/16-18x1 -1 /8 in. Hex Hd.)............................... .................. 1
22 ** STD541037 * Hex Nut (3/8-16)......................................................... .................. 4
23 976301-001 Elevating Crank Shaft................................................ .................. 1
25 976302-001 Bushing...................................................................... .................. 1
26 623111-006 Retaining Ring............................................................ .................. 1
27 622141-002 Washer....................................................................... .................. 2
28 976300-001 Elevating Shaft Bearing.............................................. .................. 1
29 706239-932 Washer....................................................................... .................. 2
30 976299-001 Bevel Pinion Gear...................................................... .................. 1
31 623111-001 Retaining Ring............................................................ .................. 1
32 ** STD571450 * Lock Nut (1/2-13)........................................................ .................. 1
33 976298-001 Bevel Gear................................................................. .................. 1
34 976297-001 Bearing ...................................................................... .................. 2
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
__ *
71 CRflFTSMfir RADIAL SAW 315.220100
