OPERATION

NON-THROUGH CUTS

See Figure 50.

WARNING: Unplug the saw while removing or
replacing the blade guard. Turn on the saw with
the switch on the arm to confirm the blade is not
receiving power.

■ Remove the blade and blade guard (see Assembly

section).

■ Place a support the same height as the saw table

nearby for the cut work. Lower the blade with the
elevating handwheel.

■ Make sure the wood is not touching the blade.

Insert the key and turn on the saw. Let the blade

build up to full speed before contacting the work
piece.

yv WARNING; Always use pushblocks when

making non-through rip cuts to avoid the risk of
serious injury. Never feed wood with your hands.

■ When the work is completed, press the switch off

and remove the key.

NON-THROUGH CUT

CRAFTSMAN'

RADIAL SAW 315.220100
