CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number in all correspondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE H
KEY
NO.
PART
NUMBER
DESCRIPTION
QUAN.
1
610122-006
* Screw (8-32 x 5/8 in.Pan Hd.)....................................................................................... .................................... 3
2
976449-001
Handle Assembly......................................................................................................... .................................... 1
3
971665-001
Switch Trigger.............................................................................................................. .................................... 1
4
977207-001
Cam Lever.................................................................................................................... .................................... 1
5
998196-001
Spring........................................................................................................................... .................................... 1
6
607617-003
0-Ring........................................................................................................................... .................................... 1
7
977203-001
Knob............................................................................................................................. .................................... 1
8
976336-001
Wiring Insulator............................................................................................................. .................................... 1
9
STD510605
* Screw (6-32 X 1/2 in. Pan Hd. T.C.)............................................................................. .................................... 2
10
967917-001
Cord Clamp.................................................................................................................. .................................... 1
11
976785-001
Cord Harness............................................................................................................... .................................... 1
12
** STD510803
* Screw (8-32 x 3/8 in. Pan Hd.)...................................................................................... .................................... 1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
>
