CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220100
The model number will be found on a plate attached to the base. Always mention the model number in all correspondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART KEY PART
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER DESCRIPTION QUAN.
1 976830-001 Lower Arm Cover...................................... .1 28 976354-001 Miter Indicator.................................. ......... 1
2 ** STD611006 * Screw (10-16 X 5/8 in. Pan Hd.)................. .4 29 980532-001 Miter Scale Label............................. ......... 1
4 980667-001 Cord Label (Control Cut Power Cord)...... . 1 30 980447-001 Strain Relief..................................... ......... 2
5 976793-001 Control Cut Power Cord........................... . 1 31 641700-008 * Screw (10-32 X 5/8 in. Round Hd.).. ......... 4
6 980669-001 Cord Label (Motor Power Cord)............... . 1 32 976327-002 Arm Cover........................................ ......... 1
7 976786-001 Motor Power Cord..................................... . 1 33 980550-001 Guard Label..................................... ......... 1
8 976834-002 * Bolt (3/8-16x2-1/4 in. Sq. Hd.) .................. .2 34 976393-001 Guard Assembly.............................. ......... 1
9 ** STD511103 * Screw (10-32 X 3/8 in. Pan Hd.)................. .1 35 980697-001 Guard Warning Label....................... ......... 1
10 989001-002 Cable Clamp............................................. .2 36 981241-001 Warning Label.................................. ......... 1
11 ** STD600803 * Screw (8-32 x 3/8 in. Pan Hd. T. C.)......... . 4 37 980542-001 Miter Lock Label............................... ......... 1
12 976342-001 Arm Bearing.............................................. .2 38 980544-001 Warning Label (Right Side)............. ......... 1
13 703776-098 * Washer...................................................... .4 39 976331-001 Arm Cap .......................................... ......... 1
14 ** STD541437 * Lock Nut (3/8-16)....................................... .2 40 980546-001 Warning Label (Left Side)................ ......... 1
15 967917-001 Cord Clamp............................................... .2 41 976863-001 Switch Key....................................... ......... 1
16 990908-009 * Screw (6-19 X 5/8 in. Pan Hd.)................... .4 42 ** STD510803 * Screw (8-32 x 3/8 in. Pan Hd.)......... ......... 1
17 976384-001 Rear Cover................................................ .1 43 976862-002 Switch.............................................. ......... 1
18 STD511103 * Screw (10-32 X 3/8 in. Pan Hd.)................. .3 44 ** STD551131 Lock Washer.................................... ......... 1
19 621380-007 * Screw (3/8-16 X 2-1/8 in. Hex Hd. Locking) .2 45 977471-001 Tag................................................... ......... 1
20 976328-001 Arm Cover Pad.......................................... .1 46 969220-005 * Screw (5/16-18 X 3/8 in. Socket Hd.' ........ 1
21 624282-003 Square Nut (3/8-16).................................. .2 47 976368-001 Cord Clamp...................................... ......... 1
24 980534-001 Control Cut Warning................................. .1 48 ** STD512505 * Screw (1/4-20 x 1/2 in. Pan Hd.)...... ......... 1
25 976829-001 Upper Arm Cover...................................... .1 49 642409-002 * Screw (10-16x41/64 in. Pan Hd.).. ......... 4
26 ** STD511105 * Screw (10-32 X 1/2 in. Pan Hd.)................. .2 50 976369-001 Cable Bracket.................................. ......... 1
27 976344-001 Miter Cap................................................... .1
51 618364-000 Control Cut Label ............................ ......... 1
* Standard Hardware Item -~ May Be Purchased Locally
** Available From Div. 98 — Source 980.00
