Table 4D — Physical Data, 40QNE/H Heat Pump High Wall Units
UNIT
40QNE009*
40QNH012*
NOMINAL CAPACITY (Tons)
%
1
NOMINAL SIZE (Btuh)
9000
12,000
OPERATING WEIGHT (lb)
18.7
24,2
MOISTURE REMOVAL RATE (PInts/hr)
2.4
3.4
REFRIGERANT
R-22
Control (Cooling)
Accu Rater® Piston at Outdoor Unit
Control Seating)
AccuRater Piston at Outdoor Unit
Factory Charge (lb)t
_...... ... ............ _..15.................. ...............
2.0
INDOOR FAN
Direct Drive Centrifugal
RpmyCfm High
1200/240
1040/260
RpnrVCfm Medium
1100/210
940/240
Rpm/Cfm Low
1000/180
850/210
Motor Watts
34
35
Blowers Quantity...Size (in.)
1...3.54 * 27.75
1...3.94 X 27.75
INDOOR COIL
Copper Tube, Aluminum Fin
Face Area
1.45
1.6
No. of Rows
2
2
Fins/in.
18
17
Circuits
2
3
FILTERS
Cieanabie
Quantity...Size (in.)
2...9X 12
2...91/4X 13V4
AIRSWEEP
Horizontal
Manual
Vertical
Automatic
CONTROLS
Integrated Microprocessor
Remote Controller Options
Wireless
Diagnostics
Yes
Defrost Method
Demand Defrost
Timer Mode
Yes
Warm Start Feature
Yes
Test Mode
Yes
Freeze Protection
Yes
Dehumidification Mode
Yes
Fan Mode
High/Medium/Low/Auto
Auto Changeover
Yes
Auto Restart
Yes
Control Voltage
115 V
230 V
REFRIGERANT LINES
Connection Type
Male Flare
Liquid Line OD (in.)
W
Vapor Line OD (in.)
Vi
Maximum Length (m
35
35
Maximum Lift (Fan Coil Above) (ft)
16
16
Maximum Lift (Fan Coil Below) (ft)
30
30
CONDENSATE DRAIN SIZE (in.)
% OD, Vie ID
'These units may oniy be matched with 38BK outdoor units. The 40QNH unit available in size 012 only.
tFuil factory charge is shipped in the outdoor unit. The charge is determined based on 25 ft of line.
