Table 4A — Physical Data, 38AN Cooling Only Condensing Units*
UNIT 3SAN 009 012
NOMINAL CAPACITY (Tons) % 1
OPERATING WEIGHT (lb) 55 62
REFRIGERANT TYPE R-22
Control (Cooling) Capillary Tube
Factory Charge (lb) 1.5 1.8
COMPRESSOR TYPE Carrier Hernietic Rotary
Model EAA090111A E8B120111A
Oil (Recharge) (oz) 10.1 10.1
Crankcase Heater None
Accumulator Yes
OUTDOOR FAN Propeller, Direct Drive
Rpm 850 850
Diameter (in.)...No. of Blades 12y4...4 12У4...4
Motor Watts 87 87
Nominal Air Cfm 750 750
OUTDOOR COIL Copper Tube, Aluminum Fin
Face Area (sq ft)...No. of Rows 3.5...1 3.5...2
FIns/in. 18 17
CONTROLS
Fusible Plug (F) 210 210
Control Voltage 115 230
REFRIGERANT LINES
Connection Type Male Flare
Liquid Line OD (in.) У4 '/4
Vapor Line OD (in.t
Maximum Length (ft) 35 35
Maximum Lift Fan Coil (Above Outdoor) (ft) 16 16
Maximum Lift Fan Coil (Below Outdoor) (ft) 30 30
‘These units may only be used with 40QNB009,012 fan coil units.
Table 4B — Physical Data, 40QNB Cooling Only High Wall Units
UNIT 40QNB 009* 012*
NOMINAL CAPACITY (Tons) n 1
NOMINAL SIZE (Btuh) 9000 12,000
OPERATING WEIGHT (lb) 18.7 24.2
MOISTURE REMOVAL RATE (Pints/Hr) 2.4 3.4
FINISH White
REFRIGERANT R-22
Control (Cooling) Capillary Tube in Outdoor Unit
Factory or System Charge (ib)t 1.5 1.8
INDOOR FAN Direct Drive Centrifugal
Rpm...Cfm High 1200...240 1040...260
Rpm...Cfm Medium 1100...210 940...240
Rpm...Cfm Low 1000...180 850...210
Motor Watts 34 35
Biowers — No. ...Size (in.) 1...3.54 X 27.75 1...3.94X 27.75
INDOOR COIL Copper Tube, Aluminum Fin
Face Area (sq ft) 1.45 1.6
No. of Rows 2 2
Finsfin. 18 17
Circuits 2 3
FILTERS Cieanable
(Quantity) Size (in.) (2) 9x 12 (2) 914 X 13W
AIRSWEEP
Horizontai Manual
Vertical Automatic
CONTROLS integrated Microprocessor
Remote Controller Wireless
Freeze Protection Yes
Auto. Restart Yes
Diagnostics Yes
Timer Mode 24-Hour Startup/Shutdown Type
Test Mode Yes
Dehumidification Mode Yes
Fan Mode Hig h/Medium/Low/Auto.
Control Voltage 115 V 230 V
REFRIGERANT LINES
Connection Type Male Flare
Liquid Line OD (in.) W 14
Vapor Line OD (In.) 14 '4
Maximum Len^h (ft) 35 35
Maximum Lift Fan Coil (Above Outdoorl (ft)
Maximum Lift Fan Coll (Below Outdoor) (ft) 16 16
30 30
CONDENSATE DRAIN CONNECTION (in.) OD, Vie ID
•Units may only be matched with 38AN outdoor units.
tFull factory charge shipped in outdoor unit. Charge is determined based on 25 ft of line.
