Table 4C — Physical Data, 38BK009.012 Outdoor Heat Pump Units*
UNIT 38BK
009
012
NOMINAL CAPACITY (Tons)
V*
1
OPERATING WEIGHT (lb)
60.7
66.5
REFRIGERANT TYPE
R-22
Control (Cootingt
Control (Heating)
AccuRater® Piston at Outdoor Unit
AccuRater Piston at Outdoor Unit
Factory Charge (lb)
1.5
2.0
COMPRESSOR TYPE
Carrier Hermetic Rotary
Model
EBA095111H
EBC130111H
Oil (Recharge) (oz)
10.1
10.1
CRANKCASE HEATER (Watts)
40
OUTDOOR FAN
Propeller, Direct Drive
Rpm
850
850
Diameter (in.)...No. of Blades
12'^...4
12'/4...4
Motor Watts
87
87
Nominal Air Cfm
756
756
OUTDOOR COIL
Copper Tube, Aluminum Fin
Face Area (sq ft)...No. of Rows
3.5...1
3.5...2
Fins/ln.
18
17
CONTROLS
Fusible Plug
210 F
210 F
Accumulator
Yes
Yes
Defrost Method
Demand
Demand
Control Voltage
115 V
230 V
REFRIGERANT LINES
Connection TVpe
Male Flare
Liquid Line OD (in.)
V4
V4
Vapor Line OD (in.)
W
Maximum Length (ft)
Maximum Lift (Fan Coll Above) (ft)
35
35
16
16
Maximum Lift (Fan Coll Below) (ft)
30
30
•These units may only be used with 40QNE/H fan coil units.
