Page 5
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
UNIT
ELECTRICAL
UNIT
iT,
UNIT HEIGHT
CENTER OF GRAVITY MM/IN
CHARACTERISTICS
LBS.
KG,
"A"
X
Z
48X1036060
208/230-1-60
485
220,0
1142.5(44,98)
553.4121,0)
520.7(20.5)
421.6(16.6)
48XL036090
208/230-1-60
493
223.6
1142.5(44.98)
553.4(21.0)
520,7(20.5)
421.6(16.6)
48XL042060
208/230-1-60
507
229.0
1193.3(46.98)
553.4(21.0)
520.7(20.5)
421.6(16.6)
48X1042090
208/230-1 -60
515
233.6
1193.3(46.98)
553.4(21.0)
520.7(20.5)
421.6(16.6)
48X1048090
208/230-1-60
521
236.3
1193.3(46.98)
495.3(19.5)
539.8(21.3)
457.2(18.0)
48X1048115
208/230-1-60
521
236.3
1193.3(46.98)
495.3(19.5)
539.8(21.3)
457.2(18.0)
48XL048130
208/230-1-60
521
236.3
1193.3(46.98)
495.3(19.5)
539,8(21.3)
457.2(18.0)
48XL060090
208/230-1 -60
572
259.5
1294,9(50.98)
553.4(21.0)
508.0(20,0)
447.0(17.6)
48X1060115
208/230-1-60
572
259.5
1294,9(50,98)
553.4(21.0)
508.0(20,0)
447.0(17.6)
48X1060130
208/230-1-60
572
259,5
1294,8(50,98)
553,4(21,0)
508.0(20,0)
447,0(17,6)
TOP VIEW
CORNER lEIGHT LBS,/KG.
R^FSD TO MATL
MILLIMETERS i INI
TOP OF UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355,6
[14. ÜÜJ
DUCT SIDE OF UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50. 8 12, ÜÜJ
SIDE OPPOSITE DUCTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. ...355.6
114. 003
BOTTOM OF UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12.
1
iO. 5UJ
ELECTRIC HEAT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 914.4
lib. 003
NIC.
fsumm CLE/micEB.
MILLIMETERS [ IN]
BETWEEN UNITS, POWER ENTRY SIDE. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . 1056.8
(42. 00]
UNIT AND UNGROUNDED SURFACES, POWER ENTRY SIDE...
. . . . . . 914,0
136, 00]
UNIT AND BLOCK OR CONCRETE WALLS AND OTHER
GROUNDED SURFACES, POWER ENTRY SIDE. . . . . . . . . . . . . . . . . . . . .
. . . . . 1066.8
(42. 00]
RgQUiFO OEARAICE FOR AND ^VKIHS
MILLIMETERS (INI
EVAP. COIL ACCESS SIDE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 914,( ) [35 .OUJ
POWER ENTRY SIDE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 914,( ) [36 .00]
(EXCEPT FOR NEC REQUIREMENTS)
UNIT TOP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 914.( ) [36 .003
SIDE OPPOSITE DUCTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . 914.( ) [3b .Ü0J
DUCT PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304.E i nz .Ü0J
DIMENSIONS IN [] ARE IN INCHES
LEFT SIDE VIEW
FRONT VIEW
RIGHT SIDE VIEW
REAR VIEW
Fig. 6 - 48XL036-060 Unit Dimensions
