Table 3 - Air Delivery and Temperature Rise at Rated Heating Input

Rated Heating input (Btu/hr)

Heating Rise Range ®F (®C)

Heating Rise Either Stage, °F (®C)

Unit

High Stage

Low Stage

High Stage

Low Stage

“Efficiency”

“Comfort”

High Stage

Low Stage

High Stage

Low Stage

48XL(-,N)024040
48XL(-,N)030040

40,000

26,000

20 - 50
(11-28)

15-45

(8-25)

35

(19)

30

(17)

40

(22)

35

(19)

48XL(-,N)030060
48XL(-,N)036060
48XL(-,N)042060

60,000

39,000

25 - 55
(14-31)

25 - 55
(14-31)

40

(22)

50

(28)

48XL(-,N)036090
48XL(-,N)042090
48XL(-,N)048090
48XL(-,N)060090

90,000

58,500

35 - 65
(19-36)

35 - 65
(19-36)

50

(28)

55

(31)

48XL(-,N)048115
48XL(-,N)060115

115,000

75,000

30 - 60
(17-33)

30 - 60
(17-33)

45

(25)

50

(28)

48XL(-,N)048130
48XL(-,N)060130

130,000

84,500

35 - 65
(19-36)

35 - 65
(19-36)

50

(28)

55

(31)

Airflow delivery values for external static pressure values of up to 1 IN. W.C.

Table 4 - Heat Pump/Air Conditioner Board Status Codes

OPERATION

FAULT

AMBER LED

FLASH

CODE

POSSIBLE CAUSE AND ACTION

Standby - no call for unit operation

None

On solid, no

flash

Normal operation.

Emergency Mode

standard Ther­
mostat Control

Rapid, con­

tinuous

flashing

Unit being oontroiled by standard thermostat inputs instead of Infin­
ity Controi. Oniy high stage operation is avaiiabie. This operating
mode should be used in emergency situations oniy.

Low Stage Cool/Heat Operation

None

1, pause

Normal operation.

High Stage Cool/Heat Operation

None

2, pause

Normal operation.

System Commu­
nications Failure

16

Communication with Ul lost. Check wiring to Ul, indoor and outdoor units.

Invalid Model Plug

25

Control does not detect a model plug or detects an invalid model plug. Unit

will not operate without correct model plug.

High-Pressure
Switch Open

31

High-pressure switch trip. Check refrigerant charge, outdoor fan operation

and coils for airflow restrictions.

Low-Pressure
Switch Open

32

Low-pressure switch trip. Check refrigerant charge and indoor air flow.

Control Fault

45

Cutdoor unit control board has failed. Control board needs to be replaced.

Brown Out (230

V)

46

Line voltage < 187v for at least 4 seconds. Compressor and fan operation
not allowed until voltage^l 90v. Verify line voltage.

No 230v at Unit

47

There is no 230v at the contactor when indoor unit is powered and cooling/

heating demand exists. Verify the disconnect is closed and 230v wiring is
connected to the unit.

Outdoor Air Temp
Sensor Fault

53

Cutdoor air sensor not reading or out of range. Chm out sensor and check

wiring.

Outdoor Coil Sen­
sor Fault

55

Coil sensor not reading or out of range. Chm out sensor and check wiring.

Thermistors Out of

Range

56

Improper relationship between coil sensor and outdoor air sensor. Chm out
sensors and check wiring.

Low Stage Ther­
mal Cutout

71

Compressor voltage sensed, then disappears while cooling or heating de­
mand exists. Possible causes are internal compressor overload trip or start
relay not releasing (if installed).

High Stage Ther­
mal Cutout

72

Compressor voltage sensed, then disappears while cooling or heating de­
mand exists. Possible causes are internal compressor overload trip or start
relay not releasing (if installed).

Contactor Shorted

73

Compressor voltage sensed when no demand for compressor operation
exists. Contactor may be stuck closed or there is a wiring error.

No 230V at Com­
pressor

74

Compressor voltage not sensed when compressor should be starting. Con­

tactor may be stuck open or there is a wiring error.

Low Stage Ther­
mal Lockout

81

Thermal cutout occurs in three consecutive low/ high stage cycles. Low
stage locked out for 4 hours or until 24v power recycled.

High Stage Ther­
mal Lockout

82

Thermal cutout occurs in three consecutive high/low stage cycles. High
stage locked out for 4 hours or until 24v power recycled.

Low-Pressure
Lockout

83

Low-pressure switch trip has occurred during 3 consecutive cycles. Unit
operation locked out for 4 hours or until 24v power recycled.

High-Pressure
Lockout

84

High-pressure switch trip has occurred during 3 consecutive cycles. Unit

operation locked out for 4 hours or until 24v power recycled.
