TROUBLESHOOTING CHART*

Condenser Fan On

Condenser Air Restricted
Condenser Air Recirculating
Noncondensables in System

Refrigerant Overcharge
Improper Line Voltage
Refrigerant System Restriction
Loose Electric Connections
Faulty Run Capacitor

Condenser Fan Off

Fan Slipping on Shaft
Loose Electric Connections
Fan Motor Overload Open
Fan Motor Bearings Stuck
Fan Motor Defective

Low Suction Pressure

Low Refrig Charge

High Suction Pressure

Low Head Pressure

Defective Compressor Valves

Slightly Low Suction Pressure

Dirty Filters

Partially Restricted Airflow
Coil Partially Iced
Slightly Low on Refrigerant
Duct Restricted
Dampers Partially Closed

Evaporative Fan Running

Low Refrig Charge
Restricted Refrig Flow

Restricted Capillary
Defective TXV

Restricted Evaporator Air

Dirty or Iced Coil
Plugged Filter
Dampers Closed
Restricted Ductwork

Evaporator Fan Stopped

Defective Fan Relay
Loose Leads
Overload Open
Burned Out Motor
Broken Belt_____________

Contactor Open

Dead Transformer
Thermostat Circuit Open
Faulty Control Relay

Overload Open
Contactor Coil Open
Loose Connection

Contactor Closed

Loose Leads at Compressor
Loose Leads at Contactor
Motor Windings Open
Internal Compr Overload Open

Contactor Closed, Then Opens

Overload Opens

Compressor Stuck

Faulty CPCS Boord______________
