Carrier 48SS - Manual (Page 8)

Base unit diiiffinnslyiris (ennt
48SS018-A042 WITH OPTIONAL BASE RAIL
OPTIONAL RETURN
AIR OPENING
BURNER AND CONTROL BOX
RIGHT SIDE yjgW. ACCESS PANEL
REQ’D CLEARANCES FOR SERVICING in (mm)
Duct panel
Unit top
Side opposite ducts
Compressor
access
(Except for NEC requirements)
REQ’D CLEARANCES TO COMBUSTIBLE MATL in (mm)
. 0
36 (914)
36 (914)
36 (914)
Maximum extension of overhangs
Unit top
Duct side of unit
Side opposite ducts
Bottom of unit
Flue panel
NEC REQ’D CLEARANCES in (mm)
Between units, contiol box side
Unit and ungrounded sutfaces, control box side
Unit and block or concrete walls and other grounded
surfaces, control box side
7/8 (22.2) DIA
CONTROL ENTRY
48 (1219)
14 (356)
. . 0
9 (229)
0
30 (762)
42 (1067)
36 (914)
42 (1067)
1 13/16'
(46 2)
3 5/16 -1.,
(04 1)
1 1/4'
(31.75)
ALTERNATE POWER ENTRY
OPTIONAL SUPPLY
AIR OPENING
COMPRESSOR ACCESS PANEL
\
1 5/8' (41 3)
GAS ENTRY
1/2' - 14 NPT
GAS CONNECTION
REAR VIEW
UNIT
ELECTRICAL
CHARACTERISTICS
UNIT WEIGHT
CORNER WEIGHT
(Ib/kg)
UNIT HEIGHT
(in./mm)
lb kg A B C D E
48SS018040 208/230-1-60 296 135 87/40 68/31 82/37 59/27 27 4/697
48SS024040 208/230-1-60 327 149 103/47 49/22 1 29/59 46/21 27 4/697
48SS024060 208/230-1-60 339 155 106/48 52/24 132/60 49/22 27 4/697
48SS030040 208/230-1-60, 208/230-3-60 344 157 106/48 53/24 132/60 53/24 27 4/697
48SS030060/080 208/230-1-60, 208/230-3-60 356 162 102/46 71/32 123/56 60/27 27 4/697
48SS036060/080 208/230-1-60, 208/230-3-60, 460-3-60 360 164 92M2 82/37 117/53 69/31 27 4/697
48SS036100/120 208/230-1-60, 208/230-3-60, 460-3-60 372 169 95/43 85/39 120/55 72/33 27 4/697
48SS042060/080 208/230-1-60, 208/230-3-60, 460-3-60 399 181 101/46 92/42 125/57 81/37 31 4/798
48SS042100/120 208/230-1-60, 208/230-3-60, 460-3-60 411 187 104/47 95/43 128/58 84/38 31 4/798
G CENTER OF GRAVITY
UNIT
in /mm in /mm Y
4835018040 " 25 04/636 ' 22 72/577
48SS024040 26 90/683 3 20 17/512 3
48SS024060 26 82/681 2 20 22/513 6
48SS030040 19^W504 8 22''4/565 4 26 57/674 9 20 1/ 509 3
48SS030060/080 26 93/684 21 1/535 4
48SS036060/080 27 31/693 7 21 0/532 6
4BSS036100/120 27 23/691 6 21 0/533 1
48SS042060/080 26 87/682 5 21 0/533 1
23'Í!/606 4 26’ '4/666 8
48SS042100/120 26 81/681 21 0/533 7
' in /mm
LEGEND
CG — Centet of Giavity
COND — Condenser
LV — Low Voltage MAT'L “ Material
NEC — National Electrical Code
REQ’D — Required
NOTE: Clearances must be maintained to prevent recirculation of air
from outdoor-fan discharge
14 96/380
