NOTES:
1
If any of
the original wire furnished must be replaced, it must be
replaced with type 90 C wire or its equivalent.
2 Thermostat: HH07AT174, HH01AD040, HH01AD046, HH01PC184,
HH01PC185 Subbase: HH93AZ040, HH93AZ176
3 Use copper conductors only
Splice
Factory Wiring
Field Control Wiring
Field Power Wiring
Accessory or Optional Wiring
To Indicate Common Potential
Only, Not to Represent Wiring
