«îse unit dimensions
48SS048,060 WITH OPTIONAL BASE RAIL
0 15/16-«
1 9/16' (23 0)
(39 7)1 B
OPTIONAL RETURN
AIR OPENING
1 1/4*
01.75)
ALTERNATE POWER ENTRY
52' 49 9/16’
(1320 0) (1259 3)
1 13/16
(46 2)
OPTIONAL SUPPLY
AIR OPENING
COMPRESSOR ACCESS PANEL
REQ’D CLEARANCES FOR SERVICING in (mm)
Duct panel
Unit top
Siete opposite ducts
Compressor access
(Except for NEC requirements)
REQ'D CLEARANCES TO COMBUSTIBLE MAIL in (mm)
Maximum extension of oveihangs
Unit top
Duct side of unit
Side opposite ducts
Bottom of unit
Flue panel
NEC REQ'D CLEARANCES in (mm)
Between units, control box side
Unit and ungrounded surfaces, control box side
Unit and block or concrete walls and other grounded
surfaces, control box side
0
36 (914)
36 (914)
36 (914)
48 (1219)
14 (356)
0
9 (229)
. 0
30 (762)
42 (1067)
36 (914)
42 (1067)
UNIT
ELECTRICAL UNIT WEIGHT
CORNER WEIGHT
(Ib/kg)
lb kg A B C D
48SS048080 208/230-1-60, 208/230-3-60, 460-3-60 438 199 113/51 89/40 164/75 72/33
48SS048100/120/140 208/230-1-60, 208/230-3-60, 460-3-60 450 205 116/53 92/42 165/75 77/35
48SS060080 208/230-1-60, 208/230-3-60, 460-3-60 477 217 123/56 99/45 173/79 82/37
48SS060100/120/140 208/230-1-60, 208/230-3-60, 460-3-60 489 222 126/57 102/46 173/79 88/40
UNIT
CENTER OF GRAVITY (in /mm)
X Y Z
48SS048080 28 54/724 9 20 00/508 17 66/448 6
48SS048100/120/140 28 22/716 8 20 05/509 3 17 66/448 6
48SS060080 28 18/715 6 20 19/512 8 17 66/448 6
48SS060100/120/140 27 79/705 9 20 23/513 8 17 66/448 6
LEGEND
CG — Center of Gravity MAT’L
COND — Condenser NEC
LV — Low Voltage REQ’D
NOTE: Clearances must be maintained to prevent recirculation of air
from outdoor-fan discharge
— Material
— National Electrical Code
— Required
10
