DRY COIL AIR DELIVERY* - HORIZONTAL DISCHARGE
(Deduct 10% for 208 v)
UNIT
230 AND 460 VOLT HORIZONTAL DISCHARGE
SIZE
MOTOR
qpppn
External Static Pressure (In. wg)
48SS 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts 230 225 220 210 195 170 — - — — —
Cfm 760 745 725 695 640 540 - - - - -
High
Watts - - — - 270 235 200 - - - -
Cfm - - - - 850 700 450 - - - -
Watts 275 275 273 269 260 257 249 - - - -
Cfm 857 835 802 782 745 717 663 - - - -
024, Watts 371 368 360 349 345 326 319 304 293 - -
030 Cfm 1079 1063 1027 996 978 919 865 783 726 - -
Watts 514 493 476 460 443 425 401 378 344 - -
High
Cfm 1409 1383 1324 1282 1223 1156 1068 984 857 - -
Watts 473 447 427 418 395 367 346 337 323 - -
Cfm 1253 1253 1172 1130 1047 946 865 829 768 - -
Watts 519 500 478 459 439 410 377 357 340 — _
036 Med ------------ ----- - - ------------- ---------- ------------------ - — ------- ------- — -------- --------
Cfm 1414 1366 1287 1234 1162 1074 920 829 743 — —
Watts 667 634 609 593 564 541 506 469 436 422 -
High
Cfm 1734 1639 1563 1461 1370 1292 1157 960 829 743 -
Watts 678 635 604 580 550 520 493 455 430 - -
042
Cfm 1540 1515 1475 1430 1375 1280 1225 1128 1020 - -
High
Watts — 820 785 750 700 680 649 612 570 - -
Cfm — 1825 1750 1685 1610 1525 1485 1335 1215 - -
Watts — - 854 786 744 706 641 606 557 511 -
Cfm - - 2026 1905 1830 1752 1603 1513 1367 1228 -
Watts — - — 905 846 824 804 748 683 637 -
High
Cfm — — 2025 1905 1830 1752 1603 1398 1228 -
Watts 1000 991 970 925 904 875 849 830 819 - -
Cfm 2125 2110 2085 2046 2009 1960 1900 1845 1775 - -
060
Watts 1355 1315 1265 1212 1158 1103 987 925 880 - -
Cfm 2480 2440 2388 2336 2266 2198 2050 1968 1890 - -
Watts — — 1435 1375 1310 1265 1175 1108 1010 915 -
High
Cfm - - 2509 2450 2380 2310 2235 2160 2083 1888 -
*Air delivery values are based on operating voltage of 230 v or 460 v, dry coil, without filter
Deduct wet coil and filter pressure drops to obtain external static pressure available for ducting
NOTES
1 Do not operate the unit at a cooling airflow that is less than 350 cfm for each 12,000 Btuh of
rated cooling capacity Evaporator coil frosting may occur at airflows below this point.
2 Dashes indicate portions of table that are beyond the blower motor capacity or are not
recommended
