Table 1 — Weight Distribution (ib)
UM!T
30( )--
APPROX
OPERWT
HK HL
HK HL A I B C D A B C D
015 1637 1016 142j 201 755 539 266 266 242 242
020 1787 1136 182| 240 790 575 296 296 272 272
025 1980 1310 3031 205 592 880 367 285 285 373
030 1985 1334 3031 205 592 885 377 290 290 377
Location of mounting holes:
WATER
i
INLET 1 PLAN VIEW
i
END
FRONT
SC l F-I l OCKIN ö
0OLT
—
J_
SNOb&ER Ft.ANo>--0
WASHER
NEOPHENE
SNUSSKR
'COMPRESSOR FOOT
ISfL A'lON S-RING
Fig. 2 — Compressor Mounting
To ensure safe moving, unit should remain on
shipping skid until final placement. If unit is moved
on rollers, use minimum of 3. Unit can also be
dragged into final position (must be on skid).
When rolling or dragging, apply force to the skid,
not the unit. Use care to avoid damage to piping and
control box.
PLACEMENT
When unit is in final position, remove skid, level
unit with a spirit level and bolt to floor or pad.
These units are not suitable for unprotected
outdoor use.
Carrier recommends that these units be located
in the basement or on the ground floor. However,
if it is necessary to locate unit on an upper floor,
be sure the structure has been designed to support
the weight. If necessary, add structural support to
floor. Also, be sure surface for installation is level.
Refer to Fig. I for space requirements and Table 1
for weight distribution.
