50DF Modu-Pac® |
FAN PERFORMANCE
CFM 1.00 1.20 1.40
Rpm Bhp Rpm Bhp Rpm Bhp
4000 788 1 45 844 166 897 1 89
4500 817 1.74 870 1 98 920 2 22
5000 850 2.09 900 2 34 948 2 61
5500 886 2 50 933 2 77 978 304
6000 922 2 95 969 3 26 1012 3 56
6500 959 3 46 1005 3 79 1048 4.13
7000 999 4.03 1042 4.39 !1084 4.75 :
7500 1039 4.69 1081 5.06 ¡1121 5.44 ■
8000 1080 ! 5.42 1121 5.81 11S9 6.21 i
5000 807 2 49 872 3 10 934 3 78
5500 821 2 65 884 3 28 944 3 94
6000 836 2 84 899 3 47 957 4 16
6500 857 3 10 913 3 70 971 4 38
7000 880 3 42 933 3 99 986 4 65
7500 904 3 76 956 4 36 1005 4 98
8000 928 4 15 980 4 76 1028 5 40
8500 955 4 59 1004 5 20 1052 5 87 •
9000 983 5 09 1029 5 70 1076 6 36 ;
9500 1012 5 63 1057 6 26)1100 ! 5.92;
10000 1040 6,20 1085 6.87 ;1127 7.53 ;
6000 789 2 47 845 2 87 889 3 21
6500 806 2 76 862 3 20 914 3 63
7000 827 3 12 878 3 54 930 4 02
7500 846 3 50 899 3 95 946 4 41
8000 866 3 92 919 4 40 967 4 88
8500 890 4 41 938 4 83 987 5 39
9000 916 4 94 960 5 42 1006 5 94
9500 940 5 49 985 6 03 1026 6 54
10000 964 6 09 1010 6 67 1051 7 22
10500 990 6 75 1034 7 35 1076 7.96
11000 1016 7 50 1059 8 10 1100 8.70
11500 1042 8 20 1085 8.90 1125 9.50
12000 1069 9,00 1110 9.70 i1150 ;10.40
8000 814 413 872 491 928 5 76
9000 840 4 78 898 5 60 951 6 47
10000 870 5 60 924 6 40 977 7 30
11000 903 6 60 954 7 40 1004 8 30
12000 937 7 80 987 8 70 1034 9 50
13000 977 9 10 1022 1000 1068 11.00
14000 1017 10 60 1060 11 60 i1102 12.60
15000 1060 12 40 1101 13.40 :i140 14.40
16000 1104:14.30 1142 15.30 ¡1181 16.40
EXTERNAL STATIC PRESSURE (in. wg)
10000 811 4 51 870 5 26 925 606
11000 832 5 18 889 5 96 943 6 78
12000 855 5 91 911 6 77 963 7 62
13000 879 6 72 933 7 64 985 8 57
14000 906 7 67 957 8 58 1007 9 58
15000 933 8 71 983 9 68 1031 10 67
16000 961 9 86 1010 10 89 1057 11 93
17000 992 11 18 1038 1221 1084 1331
18000 1025 12 65 1067 13 68 1111 14.81
19000 1058 14 30 1099 15 33 1139 16.46
20000 1092 16.11 1132 i17.17 1170 1829
EXTERNAL STATIC PRESSURE (in. wg)
CFM 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.25
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
12000 855 5 91 924 6 97 988 8 05 1049 9 20 1107 1039 1161 11 58 1213 12 78 1263 1403 1312 15 30 1359 16.54
13000 880 6 73 946 7 88 1009 9 01 1068 10 19 1124 11 42 1179 12 70 1230 1400 1279 15 29 1326 16 60 1373 17 96
14000 906 7 67 970 8 82 1031 10 09 1089 11 30 1143 12 57 1196 13 89 1247 15.26 1297 16 65 1344 18 05 1388 1944
15000 934 8 72 996 9 94 1054 11 20 1110 12 55 1165 13 85 1216 15 21 1266 16.61 1314 18 06 1361 19 54 1406 21 04
16000 963 9 90 1022 11 16 1079 12 46 1134 13 84 1186 15 29 1237 16 67 1286 18 11 1333 19 59 1378 21 12 1423 22 68
17000 993 11 20 1050 12 51 1106 13 88 1158 15 26 1209 16 75 1259 18 29 1307 19 75 1353 21 27 1397 22 83 1441 24 44
18000 1024 12.65 1080 14.01 1133 15,41 1185 16.88 1234 18.34 1282 19.94 1329 21.57 1375 23,12 1419 24.71
19000 1058 14 30 1110 15 64 1162 17 10 1212 18 60 1260 20 16 1307 21 71 1352 23 40 1396 25 13 1440 26 78
20000 1092 16 11 1141 17 44 1191 18 96 1240 20 49 1287 22 10 1332 23 73 1376 25 37 1420 27.15
21000 1126 18 07 1175 19 47 1222 20 94 1269 22 56 1314 2419 1359 25 89 1402 27,60 1444 29.32
22000 1161 20 17 1208 21 67 1253 23 13 1298 24 78 1343 26.48 13 86 28.20 1429 29 99
23000 1196 22 42 1243 24 05 1287 25 58 1329 27 18 11373 28.95 1415 S30.71
24000 1231 24 83 1277 26.59 1320 28.22 1361 29.81 1403 31.56 1444 :33.42
25000 1266 27 40!1312! 29,30|1355 31.04 11395 132.70 1434 34.40
. A.,
Optional fan motor or drive is required
I Optional fan motor and field-supplied drive required
Bhp — Brake horsepower
Rpm — Revolutions per minute
NOTES;
1 Fan performance has deductions for unit casing losses, wet coil and clean standard filters
2 Fan motor bhp is based on minimum voltages and 80 F air across motor
3 Field-supplied indoor air fan drive data is shown in Application Data
