48 ELS100-24TXG User Interface ELS100-24TXG
Figure 3-21 Port Statistics Screen (continued)
Field Description
Multicasts Transmitted Total number of multicast frames transmitted on the
port.
Multicasts Received Total number of multicast frames received on the
port.
Bytes Transmitted Total number of bytes transmitted on the port.
Bytes Received Total number of bytes received on the port.
Pause Frames Transmit-
ted Total number of flow control pause frames transmit-
ted on the port.
Pause Frames Received Total number of flow control pause frames received
on the port.
Collisions Total number of collisions detected on the port.
Late Collisions Total number of late collisions detected on the port.
CRC/Alignment Errors Total number of frames received on the port which
had either a CRC or an alignment error.
Undersized Frames Total number of frames received on the port which
were undersized.
Oversized Frames Total number of frames received on the port which
were oversized.
Fragments Total number of frames received on the port which
were fragments.
Jabbers Total number of frames received on the port which
were jabbers.
64 Byte Frames Total number of frames received and transmitted on
the port which were 64 bytes in length.
65 to 127 Byte Frames Total number of frames received and transmitted on
the port which were from 65 to 127 bytes in length.
128 to 255 Byte Frames Total number of frames received and transmitted on
the port which were from 128 to 255 bytes in length.
256 to 511 Byte Frames Total number of frames received and transmitted on
the port which were from 256 to 511 bytes in length.
512 to 1023 Byte Frames Total number of frames received and transmitted on
the port which were from 512 to 1023 bytes in length.
1024 to 1518 Byte Frames Total number of frames received and transmitted on
the port which were from 1024 to 1518 bytes in
length.
Selection Description
Refresh Refreshes port statistics.
Clear Clears (or sets to zero) port statistics.
